AXIS P3935-LR Network Camera
Best-in-class dome with IR for advanced onboard surveillance.
• Vandal-resistant, metal casing
• Complies with EN50155, EN45545, and NFPA 130
• Lightfinder and Forensic WDR
• Invisible IR LEDs, built-in microphone, and EIS
• Enhanced security features
AXIS P3935-LR is specially designed for surveillance onboard vehicles and rolling stock such as trains, buses, and emergency vehicles. This robust, vandal-resistant camera offers improved imaging, IR and microphone, enhanced security features, and extended capabilities for analytics.
Superior image quality for onboard surveillance, 24/7
AXIS P3935-LR is packed with useful features ideal for onboard surveillance and changing light conditions. It offers Axis Forensic WDR for high-quality images even when there’s both dark and light areas in the scene and Axis Lightfinder for sharp, color images in poor lighting conditions. This is particularly useful when a vehicle goes into a tunnel or under a bridge. And thanks to a built-in invisible IR LEDs (940 nm), it can be used for video surveillance in complete darkness that won’t distract the driver or passengers. Furthermore, it can be mounted forward-facing on the vehicle’s dashboard and record everything from the driver’s perspective, ideal for police vehicles and ambulances. Plus, in this scenario, electronic image stabilization (EIS) ensures stable video when the camera is subject to vibrations, perfect for capturing scenes outside the vehicle.
Optimized for transportation industry
Specifically designed for onboard surveillance, AXIS P3935-LR complies with transportation industry regulations including EN50155, EN45545, and NFPA 130. This robust dome camera comes in an IP66-, IP67-rated metal casing that protects it against water, corrosion, and dust. The casing is also vandal resistant with IK10 rating. For added peace of mind, it offers block view detection, so you’re informed if the camera view is blocked by objects or spray paint, or if the camera is out of focus. With product versions including M12 and RJ45 connectors, it can be easily installed in any kind of vehicle. AXIS P3935-LR has powerful capacity for analytics so it’s easy to add whatever analytics you need. Furthermore, it comes with a built-in microphone and external microphone input, allowing for audio surveillance and detection.
Keeping you secure
AXIS P3935-LR is crammed with advanced security functionality to prevent unauthorized access and safeguard your system. Signed firmware and secure boot guarantee that the firmware hasn’t been altered and ensure only authorized firmware is installed. And if needed, secure boot guarantees that the camera is completely free of malware after a factory default.
A whitepaper can be found in the Whitepaper PDF file
Wide Dynamic Range - WDR
For maximum forensic value and usability in scenes with both very bright and very dark areas.
Lightfinder
Capture color images in low-light conditions.
Electronic image stabilization
Minimize the impact of vibration and shaking.
Analytics
Make your network camera solution more intelligent with powerful analytics and functionality.
AXIS Fence Guard
For intruction detection
AXIS Loitering Guard
For detecting loiterers
AXIS Motion Guard
Smart motion detection
AXIS Video Motion Detection
Performance
Preset points
Yes
PTZ modes
Digital PTZ
Fog proof
Yes
Type
IP security camera
PTZ control
Yes
Wide Dynamic Range (WDR)
Yes
Day/night mode
Yes
Design
IK code
IK10
Fog proof
Yes
Form factor
Dome
Product colour
Black, White
Mounting type
Ceiling
IP RatingIP66, IP67
Housing material
Aluminium
Camera
Minimum illumination
0.01 lx
Viewing angle, horizontal
110°
Viewing angle, vertical
62°
Tilt angle range
15 - 90°
Pan range
-30 - 30°
Angle of rotation
350°
Camera pan control
Yes
Camera tilt control
Yes
Progressive scan
Yes
Image sensor
Sensor type
CMOS
Progressive scan
Yes
Optical sensor size
25.4 / 2.9 mm (1 / 2.9")
Number of sensors
1
Lens system
Number of lenses
1
Fixed focal length
2.8 mm
Video
Image quality adjustment
Brightness, Contrast, Sharpness
Text caption overlay
Yes
Privacy masking
Yes
Image stabilizer
Yes
Bit rate control
Variable Bit Rate (VBR)
Video compression formats
AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
Maximum resolution
1920 x 1080 pixels
Supported graphics resolutions
160 x 120, 160 x 90, 1280 x 960, 1920 x 1080 (HD 1080)
Frame rate
45 fps
Video streaming
Yes
Total megapixels
2 MP
Audio
Sample rate
48 kHz
Audio system
1-way
Audio formats supported
AAC-LC, G.711, LPCM, PCM
Network
Ethernet interface type
Fast Ethernet
Networking standards
IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Quality of Service (QoS) support
Yes
Number of users
8 user(s)
Streaming method
Multicast
Ethernet LAN
Yes
Supported network protocols
IPv4, IPv6 USGv6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT
Storage
Card reader integrated
Yes
Compatible memory cards
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory
512 MB
Ports & interfaces
Microphone in
Yes
Ethernet LAN (RJ-45) ports
1
Connectivity technology
Wired
Security
Video motion detection
Yes
IP address filtering
Yes
HTTPS encryption
Yes
Active tampering alarm
Yes
Password protection
Yes
Power
Power source type
PoE
Power consumption (max)
11.8 W
Power consumption (typical)
6.6 W
Operational conditions
Operating temperature (T-T)
-40 - 55 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 95%
Full specification and details can be found in the Product Datasheet PDF file
