Vertiv Avocent LV4010P-201 Single DVI KVM Extender Transmitter & Receiver

Avocent LV 4010P KVM Extender

Avocent LongView extension solutions enable you to increase the distance between the user and the target system. Extension solutions are ideal for broadcast, IT, industrial, transportation, emergency management and defense/military applications.

The LV4000 high performance KVM (Keyboard, Video and Mouse) extenders enable you to locate your critical computing hardware in a secure and temperature controlled environment, away from the user work station environment, while maintaining the same user experience.

The LV4000 Series can transmit a single or two single Link DVI video streams, USB 2.0 and analog audio over a single or multiple CATx cables. The LV4000 series has been designed to provide industry-leading video clarity, compatibility and high rack densities.

Perfect digital video, real time control

The LV4000 Series extenders use an uncompressed system whereby every pixel of every frame is sent without loss. HDMI video and audio can be extended with the correct adapter cable, although HDCP and CEC are not supported.

50 meters over a single CATx cable

Video, USB 2.0 (Low and Full speed) and audio all pass along a single cable, providing up to 50m (150ft) of extension. The second video head requires a separate CATx cable.

Power efficiency

The LV4000 Series extenders are designed to be highly power efficient and run with the minimum of input. In fact, the transmitter unit is so energy efficient that it can be powered solely from the host computer USB connections.

EDID management

The system has intelligent EDID management to allow the true characteristics of the monitor to be passed back to the computer.

High Performance KVM Features

• Plug and play - The LV4000 Series extenders are delivered in a zero config state so you can plug them in and start working with them straight away. There's no need for drivers or software to be installed.
• USB 2.0 - Enables connection of any USB human interface device from mice and keyboards through to graphics tablets, touchscreens, jog shuttles, joysticks, 3D explorers and mass storage devices. Full speed (12Mbps) isochronous devices such as headsets are supported.
• Analog audio - Stereo CD quality (stereo channel 16 bit sampled at 44.1kHz) is available to transfer audio from local to remote for line out.
• Digital video - Single or dual screens at 1920 x 1200 @ 60Hz maximum resolution.
• Rack options - Both transmitter and receiver units can be used stand-alone or up to 16.
