Ubiquiti UniFi AC In-Wall Wi-Fi Access Point - 5 Pack - UAP-AC-IW-5

Expand Your WiFi Discreetly with the Ubiquiti UniFi AC In-Wall Wi-Fi Access Point (5-Pack)

Upgrade your home or business WiFi with the Ubiquiti UniFi AC In-Wall Wi-Fi Access Point (5-Pack). This value bundle delivers five access points that seamlessly integrate into your existing wall cavity, providing powerful WiFi coverage while maintaining a clean aesthetic.

Featuring Wi-Fi 802.11ac, 3x3 MIMO technology and a sleek industrial design, the UniFi AP-AC is a Ubiquiti Networks Access Point (AP), ideal for deployment of high-performance wireless networks.

The Power of PoE

Turn existing wiring into per-room Wi-Fi with the UniFi PoE Switch series.*

* Requires Cat5e or higher

	UniFi PoE Switch
	UniFi In-Wall AP Deployments

Versatile Data and PoE Output

• An Ethernet wall jack becomes an access point, a gigabit switch, and a PoE power source.
• Wire a workstation and power a VoIP phone. Or power a US-8 for even more Ethernet ports.

Easier Than You Think.

Ideal for new and retrofit installations, the UniFi® AC In-Wall is designed to convert an Ethernet wall jack into a dual-band 802.11ac Wi-Fi access point with two Gigabit Ethernet ports.

	Scalable. Dedicated Wi-Fi per room
	Easy Setup, Monitoring, and Control
	Fast. Two radios, 802.11ac

Simple and Scalable Device Management

The UniFi® Controller provides a graphical user interface for easy configuration and monitoring of the UniFi Switch and other UniFi devices.

	Simple Setup Download the app and set up your unit in under 60 seconds.
	Know Your Network Easily keep track of your devices, clients, and data usage
	Stay Secure Keep track of all of your network security with constant reporting.

Access Point Comparison Chart

	UAP-AC-IW	UAP-AC-IW-PRO	UAP-IW-HD	UAP-AC-LITE	UAP-AC-LR	UAP-AC-PRO
Environment	Indoor	Indoor	Indoor	Indoor	Indoor	Indoor/ Outdoor
Simultaneous Dual-Band
2.4 GHz Speed	300 Mbps	450 Mbps	300 Mbps	450 Mbps	450 Mbps	450 Mbps
2.4 GHz MIMO	2x2	3x3	2x2	3x3	3x3	3x3
5 GHz Speed	867 Mbps	1300 Mbps	1733 Mbps	867 Mbps	867 Mbps	1300 Mbps
5 GHz MIMO	2x2	3x3	4x4	2x2	2x2	3x3
Range			122 mt	122 mt	183 mt	122 mt
Secondary Ethernet Port	(2 Additional Ports)	(2 Additional Ports)	(4 Additional Ports)
PoE Mode	802.3at PoE+	802.3at PoE+	802.3af PoE 802.3at PoE+	802.3af/A PoE 24V Passive PoE	802.3af/A PoE 24V Passive PoE	802.3af/A PoE 24V Passive PoE
PoE Passthrough			*
Ceiling Mount
Wall Mount
Wireless Uplink
DFS Certification
Dimensions(mm)	140 x 87 x 26	140 x 87 x 26	140 x 87 x 26	160 x 32.5	176 x 43	197 x 35

* Requires PoE 802.3at PoE+ switch.
** Requires Cat5e or higher

Ubiquiti Extended Warranty

Ubiquiti currently offers 1 year standard manufacturer warranty on equipment purchased through official UK distributors.

In the unlikely event that you have any issues with your Ubiquiti product within the 1 year of manufacturer warranty, please contact your account manager in the first instance. Our technical team will do everything they can to find a resolution to your problem. If a fix cannot be provided, then an RMA will need to be registered via the Ubiquiti Reseller Portal.

On all purchases made through Comms Express, we offer our customers options to upgrade the standard manufacturer warranty to a 3 or 5 year advanced hardware replacement.

Available warranty options:
