| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | DLDAP-2662 |
| Manufacturer No: | DAP-2662 |
| Delivery: | End of Life Product |
 |
Wireless AC1200 Wave 2 Dual-Band PoE Access Point
The WiFi4EU ready DAP-2662 Wireless AC1200 Wave 2 Dual-Band PoE Access Point is designed to provide wireless connectivity in public places, such as public buildings, libraries, health centres and museums, with secure and centrally manageable dual-band Wi-Fi. Utilising the cutting-edge speed of 802.11ac Wave 2, it deliveres maximum combined wireless signal rates of up to 1200Mbps and supports MU-MIMO technology that allows multiple devices to get high-bandwidth Wi-Fi signal at the same time, distributing data more efficiently. It is Passpoint® certified by Wi-Fi Alliance and complies with Hotspot 2.0, making the process of devices finding and getting access to the known network seamless.
Deliver wireless connectivity for public places, such as buildings, libraries, health centres and museums, with secure and centrally manageable dual-band Wi-Fi. Connect people to better Wi-Fi with cutting-edge 802.11ac Wave 2 speeds, and greater network efficiency and security.
It supports up to eight VLANs per band, allowing multiple SSIDs to segment users. Includes a wireless client isolation mechanism, which limits direct client-to-client communication. Moreover, Network Access Protection (NAP), a feature of Windows Server® 2008 and upwards, allows multiple levels of network access to be defined based on a client’s needs.
It can be ceiling-mounted, wall-mounted, or placed on a desk. Integrated 802.3af Power over Ethernet (PoE) support makes for more convenient indoor deployments using a single Ethernet cable.
Create highly secure wireless networks with Personal and Enterprise versions of WPA and WPA2. The AP also supports a built-in RADIUS server, RADIUS server (backend), MAC address filtering, wireless LAN segmentation, SSID broadcast disable, rogue AP detection, and wireless broadcast scheduling to protect the network.
The DNH-100 Wireless Controller provides an inexpensive, ready-made solution, and removes the need for installing and maintaining Nuclias Connect on additional hardware such as a server or PC. It supports up to 100 APs, automatically detects devices, pushes configurations, and provides robust hardware management. Simply plug in and power on.
Download our free Nuclias Connect network management software that’s designed for network privacy, control, and cost-effective scaling. It can be used as an on-premises software management platform, or as a cloud solution. Alternatively, the dedicated Nuclias Connect Hub (DNH-100)4 provides hardware-based, centralised network management.
Designed for reliable, high-speed wireless connectivity using the latest 802.11ac Wave 2 technology. It uses maximum wireless signal rates of up to 867 Mbps over the 5 GHz band and 300 Mbps over the 2.4 GHz band1.
In order to promote free Wi-Fi connectivity in public spaces, the European Commission’s WiFi4EU initiative aims to provide EU municipalities with funding for Wi-Fi equipment.
Customise your network the way you need it to perform. The AP can be used as a standalone AP or part of a centralised, scalable, multi-device deployment. Configure the AP to optimise network performance based on any one of its multiple operational modes:
Access Point - Add wireless connectivity to an existing wired network.
Wireless Client - Add wireless connectivity to one device which doesn’t have a Wi-Fi adapter.
WDS - Wirelessly combine two separate networks.
WDS with AP - Wirelessly combine two separate networks while also providing wireless connectivity to both networks.
| Physical | |
| Max. Power Consumption | 11 Watts |
| Operating Voltage | 12 V DC +/- 10% (power adapter not included) / 802.3af PoE |
| Operating Temperature | 0 to 40 °C / 32 to 104 °F |
| Temperature (Storage) | -20 to 65 °C / -4 to 149 °F |
| Humidity (Operating) | 10% to 90% non-condensing |
| Humidity (Storage) | 5% to 95% non-condensing |
| Dimensions | 170 x 170 x 28 mm / 6.69 x 6.69 x 1.1 inches |
| Weight | 316 grams |
| General | |
| Device Interfaces | 802.11a/b/g/n/ac wireless / 1 Gigabit LAN port (supports PoE) |
| LEDs | Power |
| Antennas | Two internal 3 dBi for 2.4 GHz / Two internal 4 dBi for 5 GHz |
| Wireless Frequency Range | 2.4 GHz band: 2.4 GHz to 2.4835 GHz / 5 GHz band: 5.15 to 5.35 GHz, 5.47 to 5.85 GHz |
Full specification and details can be found in the PDF file
