Ubiquiti TOUGHCable PRO (UISP-Cable-Pro) - 1000 ft

The Ubiquiti TOUGHCable PRO (UISP-Cable-Pro), formerly known as TC-PRO, is a high-performance, outdoor, carrier-class shielded Category 5e cable with an integrated ESD drain wire, designed to enhance your network’s reliability and performance.

Key Features:

• Enhanced Performance: Dramatically improves network performance.
• Weatherproof: Built to withstand harsh outdoor conditions.
• ESD Protection: Provides robust protection against ESD damage.
• Multi-layered Shielding: Ensures superior protection and signal integrity.
• Length: 1000 ft for extensive coverage.

Protection Against ESD Attacks: ESD attacks are a leading cause of device failures. Protect your network by using a grounded Ubiquiti Power over Ethernet (PoE) adapter along with Ubiquiti TOUGHCable and TOUGHCable Connectors. These components work together to safeguard against ESD attacks and Ethernet hardware damage.

Ubiquiti TOUGHCable Connectors: Specifically designed for use with Ubiquiti TOUGHCables, these connectors are available in packs of 1 or 100 pieces. They offer protection against ESD attacks and Ethernet hardware damage, allowing for rapid field deployment without soldering.

Available Options:

• 1 pc
• 4 pcs
• 10 pcs
• 20 pcs
• 100 pcs

For the latest firmware upgrades, please visit the Ubiquiti Firmware page.

Technical Specifications:

• Cable Type: CAT5e, Shielded
• Ethernet Support: Up to 1 Gbps
• Conductor Wire Gauge: 24 AWG
• Conductor: Solid Bare Copper
• Conductor Diameter: 0.500 ± 0.005 mm
• Insulation Type: Solid PE
• Insulation Thickness: AVG: 0.26 mm, MIN: 0.25 mm
• Insulation Diameter: 1.04 ± 0.03 mm
• Separation (Polyester Wrapping): Thick: 0.025 mm, Extent: 20 mm
• Anti-Crosstalk Divider: None
• Cable Shield (Aluminum Foil): Thick: 0.060 mm, Extent: 18 mm
• ESD Drain Wire: 0.4 CCS
• Rip Cord: Yes
• Jacket Material: PE
• Jacket Thickness: AVG: 0.50 mm, MIN: 0.46 mm
• Jacket Outer Diameter: 6.0 ± 0.30 mm
• Jacket Color: Gray
• Reference Standard: ISO/IEC 11801, TIA/EIA568B.2

Increased Performance

TOUGHCable™ dramatically increases your Ethernet link states, speeds and overall performance.

Extreme Weatherproof Design

TOUGHCable™ has been built to perform in even the harshest weather and environments.

ESD Damage Protection

TOUGHCable™ protects your networks from devastating electrostatic discharge attacks.

Extended Cable Support

TOUGHCable™ has been developed to increase power handling performance for extended cable run lengths.

TOUGHCable™ Connectors

Specifically designed for use with TOUGHCable™, the TOUGHCable Connectors protect against ESD attacks and Ethernet hardware damage, while allowing rapid field deployment without soldering.
