    StarTech PEXUSB3S2EI 4-Port PCI Express USB 3.0 Card - 2 External, 2 Internal - SATA Power

    4 Port PCI Express USB 3.0 Card - 2 External & 2 Internal - SATA Power - UASP Support - 2x Internal (IDC) Motherboard-Style Headers

    Add front or rear panel USB 3.0 ports to your computer case using USB 3.0 motherboard-style headers




    This PCI Express USB 3.0 card offers a cost-effective upgrade that lets you add four USB 3.0 ports to your computer through a PCIe slot. It offers two external ports plus two internal (IDC) USB 3.0 headers to help adapt your desktop or server to support a variety of USB 3.0 devices.


    Flexible and convenient port design

    With extra motherboard-style USB 3.0 headers you have the flexibility to add more internal USB 3.0 devices to your PC. When your existing headers are occupied, you can connect front panel hubs or card readers using this versatile alternative to costly motherboard and computer upgrades.

    For added convenience, the card integrates two external USB 3.0 ports, so you can plug in more devices such as external hard drives or printers.


    Simple installation and supports older devices

    The USB 3.0 card is easy to install and requires no additional drivers or software in natively supported Windows® 8.1 / 8 operating systems. Plus, it features a dual profile design that fits in standard or low-profile cases, so you can rest assured it will fit in your small form-factor system if needed.

    Connecting older peripherals isn't a problem either. So, there's no need to purchase new devices since the adapter card is backward compatible with your USB 2.0 and 1.x technology.


    Effective USB 3.0 performance enhanced by UASP

    This high-performance SuperSpeed USB 3.0 card supports data transfer rates up to 5 Gbps and is enhanced with UASP support, which can perform ~70% faster read speed and 40% faster write speed over traditional USB 3.0, when paired with a UASP-enabled enclosure.

    The PEXUSB3S2EI is ruggedly built for reliable USB 3.0 device connections and is backed by a StarTech.com 2-year warranty and free lifetime technical support.

    Note: UASP (USB Attached SCSI Protocol), is supported in Windows 8, 8.1, Server 2012 and Linux kernel 2.6.37 or later. Test results were obtained using an Intel® Ivy Bridge system, StarTech.com add-on USB 3.0 cards, a UASP-enabled StarTech.com enclosure, and a SATA III solid-state drive.



    Product Diagram:




    Applications:

    • Install as a vital hardware component when building your own computer or when upgrading your case
    • Connect external hard drives, tablets, smartphones, CD/DVD drives, MP3 players, printers, scanners, webcams and game controllers to your computer


    Features:

    • Flexibility to connect external and internal USB 3.0 devices and supports UASP
    • Fast, hassle-free setup with Windows 8 native support, and fits into standard or low-profile systems
    • Backward compatibility lets you save money and connect existing USB 2.0 and 1.x devices
    • Transfer large files at lightning speed, with throughput support up to 5 Gbps
    • Optional SATA power connector provides up to 900mA per port for high-power USB devices
    • PCIe x1 interface, compliant with PCI Express 2.0 specifications
    • Configured with full-profile bracket, half-height bracket included



    Internal USB 3.0, 2-Port Header Pinout:





    Ports & interfaces
    Internal Yes
    USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2
    Output interface SATA, USB 3.2 Gen 1 (3.1 Gen 1)
    Internal SATA ports quantity 1
    Host interface PCIe
    Expansion card form factor Full-height / Low-profile

    Technical details
    Chipset Renesas / NEC - µPD720201
    Data transfer rate (max) 5 Gbit/s
    Sustainability certificates RoHS

    Performance
    UASP support Yes
    Maximum cable length 3 m
    Chipset Renesas / NEC - µPD720201
    Data transfer rate (max) 5 Gbit/s
    Product colour Metallic, Red

    Design
    Mean time between fialures (MTBF) 1920042 h
    Maximum cable length 3 m
    Internal Yes
    Product colour Metallic, Red
    Certification CE, FCC

    Features
    UASP support Yes
    Chipset Renesas / NEC - µPD720201
    Data transfer rate (max) 5 Gbit/s

    Operational conditions
    Operating temperature (T-T) 5 - 50 °C
    Storage temperature (T-T) -25 - 70 °C
    Operating relative humidity (H-H) 20 - 80 %

    Weight & dimensions
    Width 18 mm
    Depth 92 mm
    Height 120 mm
    Weight 55 g

    Packaging data
    Package width 174 mm
    Package depth 143 mm
    Package height 33 mm
    Package weight 143 g
    Mounting brackets included Yes
    Manual Yes
    Drivers included Yes

    Full specification and details can be found in the PDF file

    An instruction manual can be found in the PDF file
