IBM x345, x346, x365, x3650 Slide Rails
This rail kit allows the specified IBM servers to be installed into most 4Post server racks. This rail kit is available with or without a cable management arm. If you have the IBM cable management arm that came with the IBM rail kit, you can use that CMA with this rail kit.
Fits 4Post, 2Post cabinets
Sliding rackmount for:
Rail OEM |
IBM |
Server Compatibility |
IBM x345, x346, x365, x3650 |
Rack Type |
4Post server racks |
Rack Type |
4Post |
Hole Type |
Compatible with the industry standard 3/8" (10 mm) square hole racks |
Rail Type |
Ball bearing slide rails |
Rack Units |
2U |
Mounting Depth Range |
22.5" to 31" (610 mm to 787 mm) |
Cable Management |
Fully articulated cable management arm with Kit P/N: 2URAIL-IBM-345-CMA |
Included Hardware |
12-24 pan head screws |
Tech Notes |
The 2URAIL-IBM-345 rail kit is compatible with the IBM cable management arm that comes with the server. Therefore, a CMA is not included in the base kit. If you do not have the original IBM CMA, order the 2URAIL-IBM-345-CMA |
Assembly Notes |
Phillips head screwdriver required |
Specifications | |
Rail OEM | IBM |
Server Compatibility |
IBM x345, x346, x365, x3650 NOTE: This kit does not work with the x3650 M2, x3850 |
Rack Type | 4Post server racks 2Post server racks using the CA-URS2P2U |
Hole Type | Compatible with the industry standard 3/8" (10 mm) square hole racks Compatible with all standard round (non-threaded) holes Compatible with all standard threads including 10-32, 12-24 and metric M6 |
Rail Type | Ball bearing slide rails |
Rack Units | 2U |
Mounting Depth Range | 22.5" to 31" (610 mm to 787 mm) 19" to 34.5" (508 to 864 mm) with -EXT kit Contact RackSolutions for solutions outside the listed depth range |
Cable Management | Fully articulated cable management arm with Kit P/N: 2URAIL-IBM-345-CMA |
Included Hardware | 12-24 pan head screws 12-24 cage nuts 10-32 pan head screws 10-32 cage nuts |
Tech Notes |
The 2URAIL-IBM-345 rail kit is compatible with the IBM cable management arm that comes with the server. |
Assembly Notes | Philips head screwdriver required |
