The 1URAIL-IBM-336 replaces the IBM rail kit. This rail kit allows the IBM X336 to be installed into most 4Post and 2Post racks. Common installation issues such as obstructions are easily resolved with the 1URAIL-IBM-336. In circumstances where the original IBM rails have been lost or damaged, the 1URAIL-IBM-336 provides an economical solution to replace the OEM rail kit.
Features
IBM x336 compatible
Mounts in any rack
Technical Specifications
Rail OEM |
IBM |
Server Compatibility |
IBM xSeries 336. IBM rails not required |
Rack Type |
4Post Standard 19" racks |
Rack Type |
4Post, 2Post |
Hole Type |
Compatible with the industry standard 3/8" square hole racks |
Rail Type |
Fixed (non-sliding) |
Rack Units |
1U |
Mounting Depth Range |
2Post center or flush: 2" - 8" (51 - 203 mm) |
Included Hardware |
10-32 and 12-24 screws supplied |
Finish |
Zinc plated |
Tech Notes |
Threaded front flange mates with the IBM thumb screws (M4x0.7 threads) |
Assembly Notes |
4Post - requires a Phillips screwdriver for installation. |
Specifications | |
Rail OEM | IBM |
Server Compatibility | IBM xSeries 336. IBM rails not required |
Rack Type | 4Post Standard 19" racks Meets EIA-310 requirements Use reducer brackets for 23" and 24" racks 2Post - center mount 2Post - flush mount |
Hole Type | Compatible with the industry standard 3/8" square hole racks Cage nuts included for square hole mounting Compatible with all standard round (non-threaded) holes Compatible with all standard threads including 10-32, 12-24 and Metric M6 |
Rail Type | Fixed (non-sliding) |
Rack Units | 1U |
Mounting Depth Range | 2Post center or flush: 2" - 8" (51 - 203 mm) 4Post: 15 7/8" - 34 1/4" (403 - 870 mm) |
Included Hardware | 10-32 and 12-24 screws supplied Cage nuts provided for square hole racks |
Finish | Zinc plated |
Tech Notes | Threaded front flange mates with the IBM thumb screws (M4x0.7 threads) Rack flange type standard "L" shaped uprights or non-standard "C", "Z" and "?" shapes |
Assembly Notes | 4Post - requires a Phillips screwdriver for installation. 2Post - requires a Phillips & straight screwdriver for installation. |
