    Prism PI 27u 600mm Wide x 800mm Deep Data Cabinet
    Please note: Cabinets with wardrobe style doors are built-to-order and therefore non-returnable.

    Please note: Flatpack Prism PI floor standing cabinets are not supplied with transport castors, heavy-duty castors or jacking feet. These can be purchased separately. To add castors or jacking feet to your order, please see our range of Prism PI castors, feet and other accessories.

    Please note: If a cable tray inclusive kit is selected, this will include 2 x 150mm cable trays

    Prism PI Cabinet Accessory Kit Options:

    Kit 1
    • Prism PI 27u 600mm(w) x 800mm(d) Data Cab with selected Door Options
    • 2 x 27U 150mm Cable Trays (Black)
    CE Part number: CA-PCT27150B (x2)

    Kit 2
    • Prism PI 27u 600mm(w) x 800mm(d) Data Cab with selected Door Options
    • 1 x 600mm x 600mm Plinth (colour will match the cabinet)
    CE Part number: CA-PPL68

    Kit 3
    • Prism PI 27u 600mm(w) x 800mm(d) Data Cab with selected Door Options
    • 2 x 27U 150mm Cable Trays (Black)
    • 1 x 600mm x 600mm Plinth (colour will match the cabinet)
    CE Part numbers: CA-PCT27150B (x2) & CA-PPL68

    Prism Data Cabinet Product Information

    The PI Data enclosure range has been designed to ensure maximum rigidity and weight loading without compromising the versatility of the solution. It can be easily modified, built and de-assembled where restrictions in space are in force. The PI range is a cost effective solution suitable for any office or data centre environment, supplied with adjustable 19-inch mounting angles, transportation castors and a configurable top panel system to incorporate fan and brush entry solutions and also provides an open base design to promote trouble free installation.

    Incorporating common features such as adjustable 19" mounting angles and fitted with transportation castors as standard, the PI range offers a configurable top panel system to incorporate fan and brush entry solutions and, also provides as open base design to promote trouble free installation.

    Cabinets can be fitted with a range of options including side panels, solid steel doors, vented glazed doors and vented steel doors, all designed to offer the flexibility to meet everyday requirements.

    Prism Data Cabinet Specifications

    Cabinet Dimensions
    Width & Depth 600mm x 600mm 600mm x 800mm 800mm x 600mm 800mm x 800mm
    U Height 27u 27u 27u 27u
    External Height 1410mm 1410mm 1410mm 1410mm
    External Width 600mm 600mm 800mm 800mm
    External Depth 600mm 800mm 600mm 800mm
    Mounting Profile Width 19" 19" 19" 19"
    Internal Working Depth 490mm 690mm 490mm 690mm
    Weight of Cabinet 80kg 85kg 85kg 90kg

    • Mounting profile's position/s: front & rear
    • Construction: bolted
    • Front door options: glass in steel surround (lockable), mesh (lockable)
    • Side panels: lockable/removable, solid with vents
    • Cable entry: top, bottom
    • Ventilation: top, small vents to side panels
    • Removable panels: front door, rear door, side panels
    • Lock positions: front door, rear door, side panels
    Data Cabinet Features and Benefits
    • Lockable/removable glass front door
    • Lockable/removable steel side and rear panels
    • 19" fully adjustable mounting profiles front and rear
    • Vented top cover (for use with a roof fan unit if necessary)
    • Open base design
    • Raised and vented top cover with cable entry
    • Comes with a set of transport castors (non-load bearing) for placement only (not included with flatpack version)
    • Available in goose grey (RAL 00A05) and black (RAL 9005)
    • Network/cabling/broadcast
    • 19" electronic equipment housing
    • Communication systems
    • IT systems
    • Vented and lockable side panels
    • Earth bonding kit
    • Full range of completing accessories
    • Supplied assembled or in a flat pack version
    • Multiple door configurations available
    • Configurable roof options to cater for overhead cable installations
    • Full range of airflow management accessories
    Data Cabinet Customisation
    1. Black or Grey (standard colours) (specific colours available or match your corporate colours - additional charges will apply)
    2. Panels and doors can be added/removed or changed as necessary: glass front & solid rear, mesh front & rear, glass front & wardrobe rear, mesh front & wardrobe rear
    3. Prism Data Cabinets can be supplied assembled or in a flat pack version
    4. Accessorize with cabinet plinths and cable trays, if the cable tray inclusive kit is selected, this will include 2 x 27U 150mm cable trays
    Please call our sales team on 0800 488 0000 for a quote on a custom cabinet.

    Prism PI Black Cable Tray Features and Benefits
    • Available in multiple height and width options to suit your Prism PI cabinet
    • Powder coated finish in black
    Prism PI Cabinet Plinth Specifications
    • Height: 100mm
    • Width: 600mm
    • Depth: 800mm
    • Construction: Welded
    Prism PI Cabinet Plinth Features and Benefits
    • Fixed plinth
    • Available in grey or black (Plinth will match the colour of the cabinet ordered in the kit)
    • Gland plates on side and rear for cable entry
