Molex PowerCat 6 Angled MOD-SNAP III Module RJ45 568A/B UTP

The PowerCat 6 Angled MOD-SNAP III module is ideal for floor box applications. The product is a fully assembled unit featuring the shuttered DataGate connector in a 37.5 x 22mm fascia (BT6C size). The angled design reduces patch cord bend radius particularly in shallow floor box installations. The Angled MOD-SNAP III Module can also be used in the MOD-SNAP range of wall plates.

The MOD-SNAP III module features the DataGate Category 6 connector. This superior RJ45 IDC includes a unique integral shutter that not only protects the connector from dust and contaminants, but the ingenious spring-loaded design also ejects improperly seated patch cords. The DataGate connector is dual color coded for either 568A or 568B wiring schedules. The DataGate connector is also backwards compatible with C5e systems.

Features & Advantages

• 37.5 x 22mm fascia
• Shuttered RJ45 DataGate connector
• Protected labeling facility
• Floor box and wall plate compatible
• Angled fascia

Technical Information

Jack Connector

• Plastic Housing: Polycarbonate, UL94V-0 rated or equivalent
• Operating Life: : Minimum 750 insertion cycles
• Contact Material: Copper Alloy
• Contact Plating: 1.27 micrometers Au/Ni
• Contact Force: 100g minimum
• Plug Retention Force: 6.8kg

IDC Connector

• Plastic Housing: Polycarbonate, UL94V-0 rated or equivalent
• Operating Life: Minimum 20 reterminations
• Contact Material: Copper Alloy
• IDC Contact Plating: Tin/Lead Plate
• Contact Force: 100g minimum
• Wire Accommodation: 22-24 AWG solid

Electrical

• Interface Resistance: 20 m?
• Initial Contact Resistance: 2.5 m?
• Insulation Resistance: >100 M?
• Minimum Backbox Depth Requirement: 25mm
• Termination Tool: 110
• Shipping Weight: 312g (Pk of 20)
