Molex PowerCat 6 Angled Euromod II Module UTP RJ45 568A/B

The Euromod modular system provides a flexible and versatile method of installation, allowing the user the choice of installing as many data outlets as required. The module is compatible with the Euromod range of wallplates and its angled design reduces patch cord bend radius, essential for C6 installations.

The Angled Euromod II module features the DataGate Category 6 connector. This superior RJ45 IDC includes a unique integral shutter that not only protects the connector from dust and contaminants, but the ingenious spring-loaded design also ejects improperly seated patch cords. The DataGate connector is dual color coded for either 568A or 568B wiring schedules and is RJ11 compatible.

Suitable for high-speed data transmission, the DataGate Category 6 connector has been designed to exceed the highest electrical performance standards in the industry. The DataGate connector is also backwards compatible with C5e systems.

Features & Advantages

• 25 x 50mm fascia
• Shuttered RJ45 DataGate connector
• Protected labeling facility
• Euromod wall plate compatible
• Angled fascia
• RoHS Compliant

Technical Information

Jack Connector

• Plastic Housing: Polycarbonate, UL94V-0 rated or equivalent
• Operating Life: : Minimum 750 insertion cycles
• Contact Material: Copper Alloy
• Contact Plating: 1.27 micrometers Au/Ni
• Contact Force: 100g minimum
• Plug Retention Force: 6.8kg

IDC Connector

• Plastic Housing: Polycarbonate, UL94V-0 rated or equivalent
• Operating Life: Minimum 20 reterminations
• Contact Material: Copper Alloy
• IDC Contact Plating: Tin matte finish
• Contact Force: 100g minimum
• Wire Accommodation: 22-24 AWG solid

Electrical

• Interface Resistance: 20 m?
• Initial Contact Resistance: 2.5 m?
• Insulation Resistance: >100 M?
• Minimum Backbox Depth Requirement: 25mm
• Termination Tool: 2.5 m?
• Shipping Weight: 325g (Pk of 20)
