| Part No: | MIPD-9624GC/AC-EK |
| Manufacturer No: | PD-9624GC/AC-EK |
| Delivery: | In Stock: 5-7 Days |
 |
The Microchip PD-9624GC/AC-EK is a high-power PoE midspan designed to deliver reliable power and data connectivity across demanding network environments. Built for modern IP devices, this 24-port solution provides up to 90W per port and supports the IEEE 802.3bt Type 4 standard, making it suitable for high-power applications such as advanced wireless access points, PTZ cameras, and IP communication systems. With plug-and-play deployment and full backward compatibility with IEEE 802.3af and 802.3at devices, it offers a practical way to extend existing Ethernet infrastructure while preparing networks for higher power requirements.
Designed to support power-hungry network devices, the PD-9624GC/AC-EK delivers up to 90 watts per port using the IEEE 802.3bt Type 4 PoE standard. This allows a single Ethernet cable to supply both power and data to demanding equipment such as multi-radio wireless access points, IP videophones, and high-resolution security cameras.
The midspan supports the latest IEEE 802.3bt specification while remaining fully compatible with earlier IEEE 802.3af and 802.3at powered devices. This ensures seamless operation across mixed device environments, allowing network upgrades without replacing existing hardware.
Supporting 10/100/1000 Mbps Ethernet speeds, the PD-9624GC/AC-EK maintains full Gigabit throughput across all connected ports. This ensures high-bandwidth applications such as HD video surveillance, VoIP communications, and enterprise wireless connectivity perform reliably.
Integrated PowerView™ Pro management provides a remote web-based interface for monitoring and controlling PoE power distribution. With SNMPv3 support, administrators can manage power allocation, monitor port status, and integrate the midspan into existing network management systems for improved operational oversight.
Part of the PD-96xxGC family, the platform is designed to support installations ranging from smaller deployments to high-density networks. The 24-port configuration provides significant power capacity while maintaining a compact rack-mountable design suitable for enterprise network cabinets.
As a plug-and-play PoE midspan, the PD-9624GC/AC-EK installs between a standard Ethernet switch and connected devices without requiring major network changes. This approach allows organizations to add PoE capability to non-PoE switches while extending the life of existing infrastructure.
The system distributes power across both spare and data pairs, delivering a nominal output voltage of 54V DC. With an aggregate power budget of up to 950W, the midspan can support multiple high-power devices simultaneously while maintaining consistent power delivery.
Integrated LED indicators provide quick visual feedback on system power and individual port activity. Green and orange indicators show how power is delivered across data and spare pairs, helping administrators identify port status and troubleshoot connections quickly.
The PD-9624GC/AC-EK operates within a temperature range of 0°C to 40°C and supports high humidity conditions up to 90% non-condensing. Its durable construction and rack-mount form factor make it well suited for controlled indoor networking environments such as enterprise server rooms and communications closets.
The Microchip PD-9624GC/AC-EK is a high-power PoE midspan designed to deliver reliable power and data connectivity across demanding network environments. Built for modern IP devices, this 24-port solution provides up to 90W per port and supports the IEEE 802.3bt Type 4 standard, making it suitable for high-power applications such as advanced wireless access points, PTZ cameras, and IP communication systems. With plug-and-play deployment and full backward compatibility with IEEE 802.3af and 802.3at devices, it offers a practical way to extend existing Ethernet infrastructure while preparing networks for higher power requirements.
Designed to support power-hungry network devices, the PD-9624GC/AC-EK delivers up to 90 watts per port using the IEEE 802.3bt Type 4 PoE standard. This allows a single Ethernet cable to supply both power and data to demanding equipment such as multi-radio wireless access points, IP videophones, and high-resolution security cameras.
The midspan supports the latest IEEE 802.3bt specification while remaining fully compatible with earlier IEEE 802.3af and 802.3at powered devices. This ensures seamless operation across mixed device environments, allowing network upgrades without replacing existing hardware.
Supporting 10/100/1000 Mbps Ethernet speeds, the PD-9624GC/AC-EK maintains full Gigabit throughput across all connected ports. This ensures high-bandwidth applications such as HD video surveillance, VoIP communications, and enterprise wireless connectivity perform reliably.
Integrated PowerView™ Pro management provides a remote web-based interface for monitoring and controlling PoE power distribution. With SNMPv3 support, administrators can manage power allocation, monitor port status, and integrate the midspan into existing network management systems for improved operational oversight.
Part of the PD-96xxGC family, the platform is designed to support installations ranging from smaller deployments to high-density networks. The 24-port configuration provides significant power capacity while maintaining a compact rack-mountable design suitable for enterprise network cabinets.
As a plug-and-play PoE midspan, the PD-9624GC/AC-EK installs between a standard Ethernet switch and connected devices without requiring major network changes. This approach allows organizations to add PoE capability to non-PoE switches while extending the life of existing infrastructure.
The system distributes power across both spare and data pairs, delivering a nominal output voltage of 54V DC. With an aggregate power budget of up to 950W, the midspan can support multiple high-power devices simultaneously while maintaining consistent power delivery.
Integrated LED indicators provide quick visual feedback on system power and individual port activity. Green and orange indicators show how power is delivered across data and spare pairs, helping administrators identify port status and troubleshoot connections quickly.
The PD-9624GC/AC-EK operates within a temperature range of 0°C to 40°C and supports high humidity conditions up to 90% non-condensing. Its durable construction and rack-mount form factor make it well suited for controlled indoor networking environments such as enterprise server rooms and communications closets.
