HPE P70195-421 ProLiant ML350 Gen11 4509Y RPS Server Tower

The HPE ProLiant ML350 Gen11 4509Y is a robust tower server tailored for small to medium-sized businesses and remote offices. Equipped with an 8-core Intel Xeon processor, 32GB of memory, and a reliable storage controller, it offers a balance of performance and scalability. Its design ensures adaptability to various workloads, making it a suitable choice for diverse business environments.

Key Features:

• Processor: Intel Xeon 4509Y 8-core processor
• Memory: 32GB-R RAM
• Storage Controller: HPE MR408i-o
• Network Controller: Broadcom BCM5719
• Drive Bays: 8 Small Form Factor (SFF) bays
• Power Supply: 1000W Redundant Power Supply
• Region: EMEA

What's New:

• Integration of the Intel Xeon 4509Y processor for enhanced performance
• Inclusion of the HPE MR408i-o storage controller for improved storage management
• Equipped with the Broadcom BCM5719 network controller for reliable connectivity
• Designed with 8 SFF drive bays to accommodate various storage needs
• Features a 1000W redundant power supply to ensure continuous operation

System Overview

The HPE ProLiant ML350 Gen11 4509Y server is engineered to deliver dependable performance for businesses requiring a versatile and scalable solution. Its configuration supports a range of applications, ensuring adaptability to evolving business demands.

Performance and Scalability

With the Intel Xeon 4509Y 8-core processor and 32GB of RAM, this server provides the necessary computing power for standard business operations. Its architecture allows for future upgrades, accommodating growth and increased workload requirements.

Storage and Redundancy

The inclusion of the HPE MR408i-o storage controller and 8 SFF drive bays offers flexible storage options. The 1000W redundant power supply ensures high availability, minimizing potential downtime.

Network and Connectivity

Equipped with the Broadcom BCM5719 network controller, the server ensures stable and efficient network connectivity, essential for seamless business operations.

Regional Compatibility

Designed for the EMEA region, this server complies with local standards and requirements, ensuring smooth integration into existing infrastructures.

---

I/O Diagram (Front 4LFF "4 Bays")

Key	Component
1	DisplayPort 1.1a
2	USB 3.2 Gen1 port
3	iLO service port
4	UID button/LED
5	NIC status LED 1
6	Health LED
7	Power on/Standby button and system power LED
8	Optical drive bay
9	Media bay filler panel
10	Serial number/iLO information pull tab
11	Box3: Default drive cage for 4LFF
12	Box2: Optional drive cage for 8SFF/4LFF
13	Box1: Optional drive cage for 8SFF/4LFF, or internal LTO tape drive

Notes:1 Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's

---

I/O Diagram (Front 8SFF "8 Bays")

Key	Component
1	DisplayPort 1.1a
2	USB 3.2 Gen1 port
3	iLO service port
4	UID button/LED
5	NIC status LED
6	Health LED
7	Power on/Standby button and system power LED
8	Optical drive bay
9	Media bay filler panel
10	Serial number/iLO information pull tab
11	Box3: Default drive cage for 8SFF*
12	Box2: Optional drive cage for 8SFF
13	Box1: Optional drive cage for 8SFF, or internal LTO tape drive

Notes: *Optional for 8SFF x4 U.3 drive kit or 12 EDSFF drive kit

---

I/O Diagram (Side)

Key	Component
1	CPU Socket 1 & 2
2	Dual USB port (Stacked, Top: USB 3.2 Gen1 port, Bottom: USB 2.0 port)
3	Megacell battery holder (Under)
4	HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device (Optional)
5	Secondary riser connector
6	Tertiary riser sideband connector
7	Serial port cable connector
8	Slot 15 OCP 2 (Optional for NIC adapter)
9	HPE NS204i-u power connector
10	Primary riser connector
11	Slot 14 OCP 1 (Optional for OROC/NIC adapter)

Notes:
1 CPU1 (bottom) shown Standard Heatsink with fully memory populated in 16 slots (32 slots in total)
2 CPU2 (top) shown Standard Heatsink with fully memory populated in 16 slots (32 slots in total)

---

I/O Diagram (Back)

Key	Component
1	HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device (Optional)
2	PCIe Slots 9-10 (Optional tertiary riser, 2nd processor required for expansion card installation)
3	Flexible Slot power supply 1
4	Flexible Slot power supply 2 (Optional)
5	VGA Port
6	External Fan connector 9
7	Slot 15 OCP 2 (Optional for NIC adapter)
8	Serial port (Optional)
9	iLO management port
10	USB 3.2 Gen 1 ports x2
11	External Fan connector 10
12	Slot 14 OCP 1 (Optional for OROC/NIC adapter)
13	PCIe Slots 1-4 (Primary riser)
14	Padlock eye
15	PCIe Slots 5-8 (Secondary riser)
16	Kensington slot
