HPE P55954-421 ProLiant ML350 Gen11 5416S RPS Server Tower

Versatile Enterprise Server for Demanding Workloads

The HPE ProLiant ML350 Gen11 is a robust 2U rack server engineered to handle data-intensive applications, hybrid cloud deployments, and virtualization tasks. Equipped with the latest Intel® Xeon® Scalable processors, DDR5 memory, and PCIe Gen5 technology, it offers exceptional performance, scalability, and security features to meet the evolving needs of modern enterprises.

Key Features:

• Supports 4th and 5th Gen Intel® Xeon® Scalable Processors with up to 64 cores per processor.
• Up to 8 TB DDR5 memory with 16 DIMM channels per processor for enhanced performance.
• Eight PCIe Gen5 slots and two OCP 3.0 slots for high-speed expansion and networking.
• Flexible storage configurations supporting up to 36 EDSFF drives, 30 SFF, or 16 LFF drives.
• Integrated HPE iLO 6 for secure and efficient remote server management.
• Advanced security features including HPE Silicon Root of Trust and TPM 2.0.

What's New:

• Introduction of 5th Gen Intel® Xeon® Scalable Processors with up to 64 cores.
• Enhanced memory support with DDR5 technology, offering higher bandwidth and capacity.
• Support for PCIe Gen5, providing improved data transfer rates and network speeds.
• Optional M.2 boot options for high-availability RAID configurations.
• Capability to support up to 8 single-wide or 3 double-wide GPUs for accelerated workloads.

Scalable Storage Solutions

The ML350 Gen11 offers versatile storage options, including configurations for up to 36 EDSFF drives, 30 SFF, or 16 LFF drives, accommodating various workload requirements and ensuring optimal performance.

Enhanced Security Measures

Incorporates HPE's Silicon Root of Trust and TPM 2.0, providing robust security to protect against firmware attacks and unauthorized access, ensuring data integrity and system reliability.

Advanced Management Capabilities

Features integrated HPE iLO 6 for comprehensive remote management, enabling administrators to configure, monitor, and update servers efficiently, reducing operational complexity.

Optimized for Hybrid Cloud Environments

Designed to support hybrid cloud infrastructures, the ML350 Gen11 delivers the flexibility and performance needed for seamless integration with cloud services and on-premises deployments.

Energy-Efficient Design

Offers various power supply options, including 800W, 1000W, and 1600W hot-plug redundant power supplies, ensuring energy efficiency and reducing operational costs.

---

I/O Diagram (Front 4LFF "4 Bays")

Key	Component
1	DisplayPort 1.1a
2	USB 3.2 Gen1 port
3	iLO service port
4	UID button/LED
5	NIC status LED 1
6	Health LED
7	Power on/Standby button and system power LED
8	Optical drive bay
9	Media bay filler panel
10	Serial number/iLO information pull tab
11	Box3: Default drive cage for 4LFF
12	Box2: Optional drive cage for 8SFF/4LFF
13	Box1: Optional drive cage for 8SFF/4LFF, or internal LTO tape drive

Notes:1 Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's

---

I/O Diagram (Front 8SFF "8 Bays")

Key	Component
1	DisplayPort 1.1a
2	USB 3.2 Gen1 port
3	iLO service port
4	UID button/LED
5	NIC status LED
6	Health LED
7	Power on/Standby button and system power LED
8	Optical drive bay
9	Media bay filler panel
10	Serial number/iLO information pull tab
11	Box3: Default drive cage for 8SFF*
12	Box2: Optional drive cage for 8SFF
13	Box1: Optional drive cage for 8SFF, or internal LTO tape drive

Notes: *Optional for 8SFF x4 U.3 drive kit or 12 EDSFF drive kit

---

I/O Diagram (Side)

Key	Component
1	CPU Socket 1 & 2
2	Dual USB port (Stacked, Top: USB 3.2 Gen1 port, Bottom: USB 2.0 port)
3	Megacell battery holder (Under)
4	HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device (Optional)
5	Secondary riser connector
6	Tertiary riser sideband connector
7	Serial port cable connector
8	Slot 15 OCP 2 (Optional for NIC adapter)
9	HPE NS204i-u power connector
10	Primary riser connector
11	Slot 14 OCP 1 (Optional for OROC/NIC adapter)

Notes:
1 CPU1 (bottom) shown Standard Heatsink with fully memory populated in 16 slots (32 slots in total)
2 CPU2 (top) shown Standard Heatsink with fully memory populated in 16 slots (32 slots in total)

---

I/O Diagram (Back)

Key	Component
1	HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device (Optional)
2	PCIe Slots 9-10 (Optional tertiary riser, 2nd processor required for expansion card installation)
3	Flexible Slot power supply 1
4	Flexible Slot power supply 2 (Optional)
5	VGA Port
6	External Fan connector 9
7	Slot 15 OCP 2 (Optional for NIC adapter)
8	Serial port (Optional)
9	iLO management port
10	USB 3.2 Gen 1 ports x2
11	External Fan connector 10
12	Slot 14 OCP 1 (Optional for OROC/NIC adapter)
13	PCIe Slots 1-4 (Primary riser)
14	Padlock eye
15	PCIe Slots 5-8 (Secondary riser)
16	Kensington slot
