HPE P65394-421 ProLiant DL20 Gen11 E?2434 PS Rack Server, 290W

Compact Powerhouse for Edge and SMB Deployments

The HPE ProLiant DL20 Gen11 Server combines enterprise-grade performance with a compact form factor, making it an ideal choice for small to medium-sized businesses and edge computing environments. Equipped with the Intel Xeon E-2434 processor, this 1U rack server delivers robust computing capabilities while maintaining energy efficiency and scalability.

Key Features

• Intel Xeon E-2434 processor with 4 cores and 8 threads, operating at 3.4 GHz (up to 4.7 GHz with Turbo Boost).
• 16 GB DDR4 ECC memory, expandable up to 64 GB, ensuring data integrity and reliability.
• Support for up to two Large Form Factor (LFF) drives, providing flexible storage options.
• Integrated HPE iLO 6 for advanced remote management and monitoring capabilities.
• Trusted Platform Module (TPM) 2.0 for enhanced hardware-based security.
• 290W power supply, balancing performance with energy efficiency.

What's New

• Introduction of the Intel Xeon E-2434 processor, offering improved performance for entry-level server workloads.
• Enhanced memory support with ECC technology, reducing the risk of data corruption.
• Updated HPE iLO 6 management engine, providing more robust remote management features.
• Improved energy efficiency with a 290W power supply, suitable for various deployment scenarios.

Performance and Scalability

The DL20 Gen11 is designed to handle a variety of workloads, from file and print services to more demanding applications. Its support for ECC memory and the latest Intel Xeon E-series processors ensures reliable performance and data integrity.

Deployment Flexibility

With its compact 1U rack design, the DL20 Gen11 fits easily into space-constrained environments. Its flexible storage options and scalable memory make it adaptable to evolving business needs.

Enhanced Security and Manageability

Security features like TPM 2.0 and HPE iLO 6 provide robust protection against unauthorized access and simplify server management tasks, ensuring that your IT infrastructure remains secure and manageable.

I/O Diagram (Front)

Key	Component
1	Access Panel
2	Optical drive bay
3	Serial number/iLO information pull tab
4	iLO Service Port (USB)
5	System Power button/LED
6	NS204i-u device bay (optional)
7	Front Fan Assembly
8	Health LED
9	NIC Status LED1
10	UID button/LED
11	USB 3.2 Gen 1 Port
12	Four-bay SFF hot-plug drive bays

1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's

I/O Diagram (Side)

Key	Component
1	Power Supply (1x500W shown)
2	M.2 Slot (Supports the iLO/M.2 Cable Kit option)
3	PCIe Riser
4	4-pin processor power connector
5	4 DDR5 DIMM slots
6	Processor shown with heatsink
7	Chassis intrusion detection switch connector
8	SlimSAS x8 port
9	Front I/O & USB 3.2 Gen 1 & iLO service port connector
10	Fan cage shown with 2 fans
11	Central fan assembly (3rd fan)

I/O Diagram (Back)

Key	Component
1	NIC ports (1Gb) NIC port 1 - iLO and production data shared port
2	Serial Port (optional)
3	Slot 1 PCIe 5.0
4	Redundant Power Supplies (2nd power supply not shown)
5	OCP 3.0 Slot
6	iLO dedicated network port (optional)
7	Display Port
8	VGA Port
9	USB 3.2 Gen1 ports

1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
