| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | FLPRO3000F50 |
| Manufacturer No: | PRO3000F50 |
| Delivery: | In Stock: 5-7 Days |
 |
Pro3000F Filtered Probe features:
| Pro3000F Filtered Probe Specifications | |
| User Interface | ON/OFF button (Push 1 second to activate, Press to turn off, Auto-off after 5 minutes) Filtered/Unfiltered Mode Button with LED (Green = Filtered, Red = Unfiltered) Volume dial Replaceable tip 3.5 mm earphone jack |
| Frequencies filtered | Pro3000F60 Probe: 60 Hz and its harmonic frequencies Pro3000F50 Probe: 50 Hz and its harmonic frequencies |
| Battery | 9V alkaline |
| Temperature | Operating: -20° C to 60° C, Storage: -40° to 70° C |
| Dimensions | 9.8 in. x 1.6 in. x 1.3 in. (24.9 cm x 4.1 cm x 3.3 cm) |
| Feature | Pro3000 Analog Tone and Probe |
Pro3000F60-KIT | Pro3000F50-KIT | Intellitone Pro 200 (MT-8200-60-KIT) |
| Analog Signal tracing | • | • | • | • |
| Digital Signal tracing | • | |||
| SmartTone™ | • | • | • | • |
| Used on Inactive Networks | • | • | • | • |
| Used on Active Networks | • | |||
| Frequency Filter | 60 Hz | 50 Hz | ||
| 3.5 mm Jack | ||||
| Replacable Tip | • | • | • | |
| Auto-Off | X (Probe - 5 minutes) | X (Probe - 5 minutes) | X (Toner= 2.5 hours, Probe = 1 hour) | |
| Wiremap | • | |||
| Signal Strength Indicator | • |
Signal Interference can be caused by multiple sources (I.e. power cables, fans, lighting, etc.) and can make tracing communication cabling almost impossible.
The Pro3000F probe utilizes innovative filter technology to obstruct signal interference to make tracing your cable easier, regardless of the work environment.
Technicians can also switch between filtered and unfiltered modes with a simple push of a button. The probe’s loudspeaker also allows for use in noisy locations and for tracing cable through drywall, wood and other enclosures. The probe also touts an auto-off feature that deactivates the probe after 5 minutes to conserve battery life.
The Pro3000F Filtered probe becomes even more useful when paired with the Pro3000 Tone Generator. The Pro3000 Tone Generator allows for direct connection to the unterminated wire using the angled bed of nails clips or terminated RJ-type jacks with the male RJ-11 plug. The tone generators strong tone and SmartTone™ technology allows for precise pair identification up to 10 miles (16 km) away.
