The DGS-3630 Series Gigabit L3 Stackable Managed Switches are designed for Small to Medium-sized Businesses (SMBs), Small to Medium-sized Enterprises (SMEs), large enterprises, and Internet Service Providers (ISPs). They deliver high performance, flexibility, fault tolerance, and advanced software features for maximum return on investment. With Gigabit Ethernet, SFP, 10 GbE SFP+, security features, and advanced Quality of Service (QoS), the DGS-3630 Series can act as core, distribution or access layer switches. High port densities, switch stacking, and easy management make the DGS-3630 Series suitable for a variety of applications..
Standard Software Image
The DGS-3630-28PC/SI comes with the Standard Image which provides core SMB and SME functionality such as L2 switching, entry-level routing, L2 multicast, advanced QoS, Operations, Administration, and Maintenance (OAM), and robust security features.Other software options/upgrades include:
The Enhanced Image supports all the features of the Standard Image in addition to full L3 routing for enterprise integration, including OSPF, BGP, VRF-Lite and L3 multicast. The MPLS Image offers all the features of the Standard and Enhanced Images in addition to VPN services for ISPs, including IS-IS and MPLS L2/L3 VPN. With multiple software images, only the required features need to be installed, providing a flexible approach to software management.The DGS-3630-28PC switch has 20 gigabit PoE+ Ports, 4 Combo SFP Ports and 4 10G uplink/stacking ports.
Features:
High Availability and Flexibility
High Bandwidth Stacking
DGS-3630-28PC: 20 x 10/100/1000BASE-T PoE Ports
4 Combo 10/100/1000BASE-T/SFP ports
4 10 GbE SFP+ uplink ports
Optional Accessories
DEM-310GT |
1000BASE-LX, Single-mode, 10 km |
|
DEM-311GT |
1000Base-SX Multi-mode Fibre Transceiver |
|
DEM-312GT2 |
1000BASE-SX Multi-mode,2 km |
|
DEM-431XT |
SFP+ 10GBASE-SR Multi-Mode Fibre Transceiver (300m) |
|
DEM-432XT |
SFP+ 10GBASE-LR Multi-Mode Fibre Transceiver (10 km) |
|
DEM-CB100S |
1mt 10G SFP+ Direct Attach Cable (DAC) |
|
DEM-CB300S |
3mt 10G SFP+ Direct Attach Cable (DAC) |
|
DPS-500A |
AC Redundant Power Supply |
|
DPS-700 |
589 Watt Redundant Power Supply |
Stackable Managed Switches
Versatile Management
The DGS-3630 Series provides:High Availability and Flexibility
Includes stacking technology, which allows multiple switches to be combined to form a single physical or virtual stack.
Scale your network using just a stacking cable and without the need for stacking modules.
Increased redundancy over multiple physical units, simplifies management and provides a single IP address to manage all members in the stack.
Security, Performance & Availability
Robust set of QoS features helps ensure that critical network services such as Voice over IP and video conferencing are given high priority through the network.
The D-Link Safeguard Engine increases the switch’s reliability, serviceability, and availability by preventing malicious flooding traffic caused by worms or virus attacks.
Power over Ethernet (PoE) Support
The DGS-3630-28PC features Power over Ethernet, which allows PoE-powered devices to be powered by the switch through a standard Ethernet cable. It supports the IEEE 802.3af PoE and IEEE 802.3at PoE+ standards, providing up to 30 W of power per port. PoE effectively reduces deployment time for PoE devices such as IP cameras, VoIP phones, and access points, and eliminates the cost for additional electrical cabling. It features a 370 W PoE power budget which can be increased to 740 W when outfitted with the DPS-700 redundant power supply, allowing the switches to power even more devices. Additionally, an extended Link Layer Discovery Protocol (LLDP) automatically negotiates and manages the power feed to IEEE 802.3at PoE+ powered devices for optimal power distribution.
