Aten VE8662 True 4K HDMI H.265 over IP Transceiver with PoE

The ATEN VE8662 True 4K HDMI H.265 over IP Transceiver with PoE delivers efficient AV-over-IP performance with True 4K video quality. Designed for maximum flexibility, it can operate as either a transmitter or receiver, providing scalable deployment from simple point-to-point setups to expansive multi-endpoint networks. Powered by advanced H.265 compression, it ensures ultra-clear, low-latency video and audio streaming over standard Ethernet infrastructure.

Key Features of ATEN VE8662

• Extends True 4K HDMI signals (3840 x 2160 @ 60 Hz, 4:4:4) with low latency via H.265 compression
• Supports HDR10 and HDCP 2.3/2.2 compliance for secure, high-quality playback
• Flexible audio options with embedded/de-embedded audio and stereo PCM 2-channel support
• Boundless mouse switching and KVM functionality for seamless control transitions
• Supports point-to-point and multi-point network configurations up to 100 meters
• Integrated Web GUI for drag-and-drop content management and source preview
• Dual power options: Power over Ethernet (PoE) and DC-in with automatic redundancy
• Supports multiple control interfaces including RS-232, Telnet, SSH, and USB
• Secure streaming with AES-128 encryption, SRTP, HTTPS, and WSS protocols
• Compatible with ATEN Control System for unified operation via touch panels or CLI
• Rack-mountable design with built-in ESD protection (8KV/15KV)

Streamlined Transceiver Setup

The VE8662 offers an effortless configuration process. With its unique ID assignment method, there’s no need for complex IP configurations. Users can easily switch between transmitter and receiver modes using a single DIP switch for quick setup and identification.

Optimized H.265 Transmission Efficiency

Featuring advanced H.265 video compression, the VE8662 minimizes bandwidth usage while maintaining visual clarity and performance. This ensures efficient 4K transmission with lower latency and reduced signal loss compared to H.264 compression.

Audio Embedding and De-Embedding

The transceiver supports audio embedding for a single HDMI connection carrying both audio and video signals. When required, audio can also be de-embedded and routed separately, ensuring compatibility with diverse AV configurations and audio systems.

Intuitive Web GUI Management

Manage and control video sources through a browser-based GUI. The web interface enables drag-and-drop video management, source switching, and customizable layout design—allowing users to preview, organize, and monitor AV content with ease.

Integrated Video Wall Control

The VE8662 provides integrated video wall functionality for both horizontal and vertical orientations. Through KVM control and an On-Screen Display (OSD) interface, users can intuitively “push” and “pull” content between operators and displays, supporting dynamic video wall collaboration and instant source switching via Boundless Switching.

Dual Power Redundancy

Equipped with both PoE and DC-in power options, the VE8662 ensures consistent operation even in case of power failure. This dual power redundancy design guarantees continuous AV transmission in mission-critical environments.

Scalable Network Expansion

The VE8662 supports a scalable AV-over-IP infrastructure, integrating seamlessly into LAN environments. Its multicast streaming and cascading capabilities allow for flexible system expansion across multiple locations and endpoints.

Applications

The VE8662 is designed for digital signage, command centers, sports arenas, casinos, and smart building installations. Its scalable and reliable AV distribution capabilities make it ideal for networked AV environments where high-quality, synchronized video delivery is essential.
