Aten KE9900ST DisplayPort Slim KVM over IP Transmitter

The KE9900ST can be set on a desk, mounted on a wall or at the rear of a rack with its space-saving 0U rack mount design. Moreover, the KE9900ST can be used as a point-to-point/point-to-multipoint/multipoint-to-point extender, or integrated into a KVM over IP Matrix System (multipoint-to-multipoint) when combined with the KE Matrix Management Software (CCKM), providing more flexible applications in different working environments.

The KE9900ST can be configured through the KE Matrix Management Software or RS-232/Telnet text menu. The KE extender also offers enhanced security features such as supporting AES encryption for secured Video/Keyboard/Mouse/USB data transmissions and RADIUS/LDAP/AD or remote user authentication that provides an added layer of connection security.

When integrated with the KE Matrix Management Software and paired with the KE Series receiver, the KE extender supports more advanced features such as boundless switching, fast switching, video wall, multi display, profile scheduling, auto detection of all KE Series extenders on the same subnet for the sake of fast installation or configuration, as well as username/password authentication and authorization. Please refer to the CCKM webpage for more details.

Whether you're configuring, monitoring, administrating, controlling or extending computer access, the KVM over IP Matrix System is made adaptable, to fit an endless variety of working environments and workstation settings, as well as to provide solutions in broadcasting, control center, multimedia, manufacturing and many other industries where matrix extending is required.

Hardware

• Advance processor provides lossless and low latency video transmissions up to 1920 x 1200 @ 60Hz; 24-bit color depth
• Support standard HDMI resolutions from 640 x 480 up to 1920 x 1200
• USB Virtual Media Support
• Compliant with DP 1.2 and HDCP 1.3
• Auto-MDIX – automatically detects cable type
• Built-in 8KV/15KV ESD protection and 1KV surge protection
• Slim, light and fanless design for silent operations that are energy efficient
• Support connection via Gigabit Ethernet port
• Rack Mountable and Wall Mountable
• Mounting options:
• VE-RMK 1U Extender Rack Mount Kit

Management

• Remotely access computers on your KVM installation via intranet
• OSD (On Screen Display) on the Receiver configures both Tx/Rx units
• EDID Expert™ – selects optimum EDID settings for smooth power-up and highest quality display
• Video Compression Level – allows you to increase/decrease the video quality to adjust for appropriate network bandwidth
• CLI – administrators can control all KE devices via RS-232 or Telnet by issuing commands
• RS-232 serial ports – allow you to connect to a serial terminal for text menu, CLI, or serial devices such as touch screens and barcode scanners
• Compatible with all KE devices

Security

• Dedicated LAN port for KE direct connections – can be isolated from the corporate network
• Secure data transmission – AES encryption to secure Video/Keyboard/Mouse/Data transmission
• Supports industry standard Transport Layer Security (TLS) protocol

Virtual Media

• Virtual Media enables file transfers, OS patching, software installations and diagnostic testing
• Support USB 2.0 DVD/CD drives, USB mass storage devices, PC hard drives and ISO images
• Support Smart Card/CAC Reader

Recommended Network Switches

• Below are the network switches that have passed ATEN's stress tests using the KE Series extenders. Our tests streamed content over a network with a resolution of 1920 x 1200 @60Hz (KE69 Series) and 3840 x 2160 @30Hz (KE89 Series), 24bit color depth at 60 frames per second:
• Cisco Catalyst 2960X / Catalyst 2960XR / Catalyst 3750
• HP Procurve 2920
• H3C S5120
• Huawei S5700
• DLink DGS-1510

Package Contents:

• 1x Slim DisplayPort Single Display KVM over IP Transmitter
• 1x DisplayPort Cable (2m/6.56ft)
• 1x USB 2.0 Type-A to Type-B Cable (1.8m/6ft)
• 1x Power Adapter
• 1x Mounting Kit
• 1x User Instructions
