| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | DC3M2529 |
| Manufacturer No: | 2529 |
| Delivery: | In Stock: 3-5 Days |
 |
The 3M™ Fibrlok™ II Universal Optical Fibre Splice 2529 is designed to easily splice any combination of 250 or 900 (mu)m coated fibres with inexpensive tooling and no electrical power.
Fibrlok single fibre optical splices utilize a metallic splicing element held inside a molded plastic body and cap to provide a fast, permanent splice. Index matching gel at the fibre splice interface helps enable a low loss splice that maintains transmission quality over the life of the network. Assembly of the inexpensive Fibrlok splice requires only removal of the fibre coating, cleaning and cleaving of the fibre.
Specifications
| China RoHS - Below MCV: | Yes |
| Cleave Type: | Flat |
| Compatible With: | BTI |
| Depth: | 0.15 Inch |
| EU RoHS Compliant: | Yes |
| Fibre Count: | 1 |
| Fibre Diameter: | 125 µm |
| Fibre Type | 250, 900 µm |
| Height: | 1.5 Inch |
| Includes Easy Cleaver: | No |
| Installation Time: | |
| Length: | 1.5 Inch |
| Mean Insertion Loss: | 0.1 dB |
| Minimum Tensile Strength: | 4.4N (1.0 lbf) |
| Mode Type: | Singlemode |
| Operating Temperature Range: | -40 to 75 Degree Celsius |
| Pigtail Connector: | No |
| Product Type: | Splice |
| Reflectance Loss: | <-40dB |
| RUS Listed: | Yes/BA |
| Splice Type: | Single Fibre |
| Trademark: | Fibrlok |
| Width: | 0.25 Inch |
| Specifications | |
| China RoHS - Below MCV | Yes |
| Cleave Type | Flat |
| Compatible With | BTI |
| Depth | 0.15 Inch |
| EU RoHS Compliant | Yes |
| Fibre Count | 1 |
| Fibre Diameter | 125 µm |
| Fibre Type | 250, 900 µm |
| Height | 1.5 Inch |
| Includes Easy Cleaver | No |
| Length | 1.5 Inch |
| Mean Insertion Loss | 0.1 dB |
| Minimum Tensile Strength | 4.4N (1.0 lbf) |
| Mode Type | Singlemode |
| Operating Temperature Range | -40 to 75 Degree Celsius |
| Pigtail Connector | No |
| Product Type | Splice |
| Reflectance Loss | <-40dB |
| RUS Listed | Yes/BA |
| Splice Type | Single Fibre |
| Trademark | Fibrlok |
| Width | 0.25 Inch |
