The 3M™ Fibrlok™ II Angle Fibre Splice 2529-AS splices any combination of 250 (mu)m and 900 (mu)m fibres.
These angle fibre splices have splice elements that have been optimized for keyed, angle cleaves and have green end caps, so they can be identified after installation. The 2529-AS splices have the same size and shape as the3M™ Fibrlok™ II Universal Optical Fibre Splice 2529 splices and can be used in the same splice trays. 3M™ Fibrlok™ AS series is specifically designed for the splicing of optical fibres in analogue video networks, which require excellent optical reflection performance across temperature extremes. Utilizing keyed, angle cleaves, these Fibrlok splices direct reflected light outside of the fibre while maintaining a very low mean insertion loss of < 0.1 dB.
Specification
China RoHS - Below MCV: | Yes |
Cleave Type: | Angle |
Depth: | 0.15 Inch |
EU RoHS Compliant: | Yes |
Fibre Count: | 1 |
Fibre Diameter: | 125 µm |
Fibre Type: | 250, 900 µm |
Height: | 1.5 Inch |
Includes Easy Cleaver: | No |
Installation Time: | |
Length: | 1.5 Inch |
Mean Insertion Loss: | 0.1 dB |
Minimum Tensile Strength: | 4.4N (1.0 lbf) |
Mode Type: | Singlemode |
Operating Temperature Range: | -40 to 75 Degree Celsius |
Pigtail Connector: | No |
Product Type: | Splice |
Reflectance Loss: | <-60dB |
RUS Listed: | Yes/BA |
Splice Type: | Single Fibre |
Trademark: | Fibrlok |
Width: | 0.25 Inch |
Specifications | |
China RoHS - Below MCV | Yes |
Cleave Type | Angle |
Depth | 0.15 Inch |
EU RoHS Compliant | Yes |
Fibre Count | 1 |
Fibre Diameter | 125 µm |
Fibre Type | 250, 900 µm |
Height | 1.5 Inch |
Fibre Count | 1 |
Fibre Diameter | 125 µm |
Fibre Type | 250, 900 µm |
Height | 1.5 Inch |
Includes Easy Cleaver | No |
Length | 1.5 Inch |
Mean Insertion Loss | 0.1 dB |
Minimum Tensile Strength | 4.4N (1.0 lbf) |
Mode Type | Singlemode |
Operating Temperature Range | -40 to 75 Degree Celsius |
Pigtail Connector | No |
Product Type | Splice |
Reflectance Loss | <-60dB |
RUS Listed | Yes/BA |
Splice Type | Single Fibre |
Trademark | Fibrlok |
Width | 0.25 Inch |
