Lindy TosLink Extenders, Adapters and Cables

Overview This neat TosLink adapter features a clever 360 degree connector design which allows it to swivel and rotate to almost any angle. It allows you to connect TosLink cables without obstructing the adjacent ports or straining connectors.

Product Details Rotates a full 360 degrees


90 degree angled


Gold plated collets


Black PVC outer shell

The Lindy USB 2.0 Sharing Hub is a handy device which allows the user to share 4 USB devices over 2 separate computers, with a simple switch for easy control over which computer has access to the hub and connected devices, a great solution in a range of IT scenarios such as accessing stored files or connecting USB peripherals including printers.

The hub is backwards compatible with USB 1.1 devices and supports PC as well as Mac computers, ensuring connectivity is hassle free whichever hardware is used.Two USB Type A to B cables are included for connecting the Hub to the computers.

Product Details

High quality fibre optic cable ensures crystal clear digital audio transmission
Compatible with all SPDIF equipped devices using the TosLink interface
Protective shell, outer diameter 2.2mm - Immune to electrical interference
Connectors: TosLink Male to TosLink Male
10 year warranty
Please Note: These cables come with a protective dust cap on each end of the cable. Remove this before installation.

3 Port TosLink (Optical) Digital Audio Splitter

Key Features:



Sends a single digital audio signal to up to 3 output devices
Supports 2-channel LPCM, DTS & Dolby Digital audio
Transmits digital audio signals up to 40m without degradation using high quality optical audio cables
Minimalistic, compact design allows for discreet installation
2-year warranty


The Lindy 3 Port TosLink (Optical) Digital Audio Splitter allows the connection of up to 3 digital optical (SPDIF, TosLink) output devices such as speakers, amplifiers or soundbars to a single digital audio source device.

Support for sampling rates up to 96kHz and audio and compatibility with multi-channel Dolby Digital & DTS audio formats ensures a reliable, loss-less audio transmission.

A compact, minimalistic design and low power requirement through USB ensures maximum flexibility within AV installations, ideal for smaller home AV configurations and larger office, education or retail applications.

Specifications:



AV Interface: TosLink (Optical)
Supported Audio: LPCM2.0 / DTS / Dolby Digital
Input: 1 x TosLink (Optical) (Female)
Output: 3 x TosLink (Optical) (Female)
Power: Mini-USB (Female)
Dimensions (approx.) WxDxH: 54x60x20mm (2.13x2.36x0.79in)
Housing Material: Plastic
Net Weight: 0.054kg (0.12lb)
Operating Temperature: 0°C - 40°C (32°F - 104°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
Humidity: 5-90% RH (non-condensing)
Power Requirements: 2.5W
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 133x105x24mm (5.24x4.13x0.94in)
Gross Weight: 0.08kg (0.18lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS, REACH & California Proposition 65


Package Contents:



3 Port TosLink (Optical) Digital Audio Splitter
USB Type A to Mini-B Cable, 0.76m
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

3 Port TosLink (Optical) Digital Audio Switch - Easily switch between 3 digital audio source devices

Key Features:

Switch between three digital audio signals from various sources to a common output device
Supports 2-channel LPCM, DTS & Dolby Digital audio
Transmits digital audio signals up to 40m without degradation using high quality optical audio cables
Easily control switching with an IR remote control or integrated push button
2 year warranty


The Lindy 3 Port TosLink (Optical) Digital Audio Switch allows the connection of three digital optical (SPDIF, TosLink) source devices to a single output device such as; speakers, amplifiers or a soundbar. A convenient push button on the device, as well as an IR remote control allows the switching of source content with ease ensuring high quality audio playback can be resumed from any source instantly.

A compact, minimalistic deign and low power requirement through USB ensures maximum flexibility within AV installations, ideal for smaller home AV configurations, and larger office, education or retail applications.

Specifications:

AV Interface: TosLink (Optical)
Supported Audio: LPCM2.0 / DTS / Dolby Digital
IR Support: Yes
Special Features: Remote Control
Input: 3 x TosLink (Female)
Output: 1 x TosLink (Female)
Control: 3.5mm (Female)
Power: Mini-USB
Dimensions (approx.) WxDxH: 54x60x20mm (2.13x2.36x0.79in)
Housing Material: Plastic
Net Weight: 0.084kg (0.19lb)
Operating Temperature: 0°C - 40°C (32°F - 104°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
Humidity: 5-90% RH (non-condensing)
Power Requirements: 2.5W
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 133x105x24mm (5.24x4.13x0.94in)
Gross Weight: 0.12kg (0.26lb)
Warranty (Years): 2
Certificated: CE, UKCA, FCC, RoHS, REACH & California Proposition 65


Package Content:

3 Port TosLink (Optical) Digital Audio Switch
USB Type A to Mini-B Cable, 0.76m
3.5mm IR Receiver Cable, 0.6m
IR Remote Control with CR2025 Battery
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

5 Port TosLink (Optical) Digital Audio Splitter

Key Features:



Sends a single digital audio signal to up to 5 output devices
Supports 2-channel LPCM, DTS & Dolby Digital audio
Transmits digital audio signals up to 40m without degradation using high quality optical audio cables
Minimalistic, compact design allows for discreet installation
2-year warranty


The Lindy 5 Port TosLink (Optical) Digital Audio Splitter allows the connection of up to 3 digital optical (SPDIF, TosLink) output devices such as speakers, amplifiers or soundbars to a single digital audio source device.

Support for sampling rates up to 96kHz and audio and compatibility with multi-channel Dolby Digital & DTS audio formats ensures a reliable, loss-less audio transmission.

A compact, minimalistic design and low power requirement through USB ensures maximum flexibility within AV installations, ideal for smaller home AV configurations and larger office, education or retail applications.

Specifications:



AV Interface: TosLink (Optical)
Supported Audio: LPCM2.0 / DTS / Dolby Digital
Input: 1 x TosLink (Female)
Output: 5 x TosLink (Female)
Power : Mini-USB
Dimensions (approx.) WxDxH: 54x60x20mm (2.13x2.36x0.79in)
Housing Material: Plastic
Net Weight: 0.057kg (0.13lb)
Operating Temperature: 0°C - 40°C (32°F - 104°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
Humidity: 5-90% RH (non-condensing)
Power Requirements: 2.5W
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 133x105x24mm (5.24x4.13x0.94in)
Gross Weight: 0.085kg (0.19lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS, REACH & California Proposition 65


Package Contents:



5 Port TosLink (Optical) Digital Audio Splitter
USB Type A to Mini-B Cable, 0.76m
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

TosLink (Optical) & Coaxial to Phono DAC - Convert high quality digital audio to an analogue audio signal

Key Features:

Converts digital coaxial or optical signals to analogue stereo audio
Supports uncompressed digital stereo audio signals with a sampling frequency of up to 24 bit / 96kHz
Digital Coaxial and Toslink (Optical) inputs for a dual connectivity solution
Minimalistic, compact design and seamless functionality
2 year warranty
ADCs and DACs allow for simple connectivity of digital or analogue audio equipment to modern, or legacy audio inputs.

The Lindy TosLink (Optical) & Coaxial to Phono DAC allows the user to easily convert uncompressed digital stereo audio signals from Coaxial and Toslink inputs to an analogue stereo audio output. This device provides a high-quality audio experience with support for a high sampling frequency of up to 24 bit / 96kHz, ensuring content can be heard exactly how the artist and sound engineers intended, with greater detail and clarity.

With both Optical and Digital Coaxial input connections, that can be connected individually or consecutively to ensure seamless compatibility, and L/R Phono outputs, this audio converter is a perfect solution for connecting Blu-Ray Players and games consoles to older audio amplifiers, receivers or 2-channel speaker systems, with no loss in audio quality for a superior 2-channel audio experience.

The converters minimalist and stylish design means that it can also be hidden out of sight to compliment the popular trend of discreet AV installations while the digital connection switch to determine which input is active ensures minimum fuss when installing or using, great for home users or professional AV installers.

Specifications:

Audio Interface: TosLink (Optical), Digital Coaxial
Chipset: IA8416
Supported Audio: LPCM 2.0
Maximum Supported Audio Sample Rate: 24-bit / 96KHz
Input Impedance: 75 Ohm
Output Impedance: 75 Ohm
Output Voltage: 0.7V
Frequency Response: 10-20KHz
Signal to Noise Ratio: 100db
Input: TosLink (Optical) (Female), Digital Coaxial (Female)
Output: Phono (R/L) (Female)
Power: 5.5/2.1mm
Dimensions (approx.) WxDxH: 51x26x41mm (2.01x1.02x1.61in)
Housing Material: Plastic
Net Weight: 0.078kg (0.17lb)
Operating Temperature: 0°C - 70°C (32°F - 158°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
Humidity: 10 - 80% RH (non-condensing)
Power Requirements: 5VDC 1A
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 145x50x107mm (5.71x1.97x4.21in)
Gross Weight: 0.17kg (0.37lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH & California Proposition 65


Package Contents:

TosLink (Optical) & Coaxial to Phono DAC
USB Type A to DC Cable, 1m
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview The Lindy Bi-directional Converter and Repeater allows the user to input digital audio through a Coaxial or optical port and output digital audio simultaneously through Coaxial and optical ports, for dual audio functionality, avoiding the need for two separate audio converters, and a high resolution listening experience of movies, games and music.

Featuring Digital Coaxial and Toslink ports as both input and output connections, this converter is perfect for converting Coaxial signals to optical, great for connecting DVD players or legacy games consoles to home cinema receivers or soundbars, or when connecting Blu-Ray players and games consoles to some surround sound systems or amplifiers via Optical to Coaxial conversion

With support for a hi-res sampling frequency of up to 24 bit / 192kHz, music can be heard exactly how the artist and sound engineers intended, with greater detail and clarity, while Dolby Digital and DTS 5.1 channel support also ensures movies are heard with dynamic multi-channel audio, for a true home cinema experience.

The dual input functionality also doubles up as a repeater, great for extending digital audio signals over longer distances that can’t be reached using only one digital coaxial or Toslink cable

The converters input selector switch, allowing the input signal to be easily changed provides simple control for both home users and professional installers, while the DAC’s ‘Plug and Play’ functionality ensures minimum hassle connectivity within an audio ecosystem

The converters minimalist, compact design means it can also be hidden out of sight or integrated into current home cinema installations.

Product Details Bi-directionally converts digital optical or coaxial SPDIF to coaxial SPDIF and digital optical


Supports digital audio up to 24 bit / 192kHz


Supports LPCM, Dolby Digital & DTS audio, from 2 to 5.1 channels


Minimalistic, compact design and seamless functionality


2 year warranty

Phono to TosLink (Optical) & Coaxial ADC - Convert analogue audio to a digital audio signal

Key Features:

Converts analogue stereo audio signals to digital coaxial or optical
Supports uncompressed digital LPCM signals
Digital Coaxial and Toslink (Optical) outputs for a dual connectivity and splitting solution
ADCs and DACs allow for simple connectivity of digital or analogue audio equipment to modern, or legacy audio inputs.
Minimalistic, compact design and seamless functionality
2 year warranty
ADCs and DACs allow for simple connectivity of digital or analogue audio equipment to modern, or legacy audio inputs.

The Lindy Phono to TosLink (Optical) & Coaxial ADC allows the user to easily convert analogue stereo audio signals to digital coaxial and Toslink (optical) output signals, for a high quality audio experience with movies, games and music.

With L/R Input connections, and both Optical and Digital Coaxial output ports, that can be connected individually or consecutively to ensure seamless compatibility, this audio converter is a perfect solution for connecting DVD Players, VCRs and older generation games consoles to home theatre receivers or soundbars. This device ensures there is no loss in quality for a superior surround-sound audio experience that enhances the impact of video or audio content. The separate dual output connectors can also work as a splitter to two separate audio receivers.

The converter's compact design ensures the device can be integrated into current installations or hidden away, while the digital connection switch to determine which input is active ensures fuss-free connectivity and use.

Specifications:

Audio Interface: Phono (R/L)
Chipset: CS8406
Supported Audio: LPCM 2.0
Maximum Supported Audio Sample Rate: 24-bit / 48KHz
Input Impedance: 75 Ohm
Output Impedance: 75 Ohm
Output Voltage: 0.7V
Frequency Response: 10-20KHz
Signal to Noise Ratio: 90db
Input: Phono (R/L) (Female)
Output: TosLink (Optical) (Female)
Digital Coaxial (Female)
Power: 5.5/2.1mm
Dimensions (approx.) WxDxH: 51x26x41mm (2.01x1.02x1.61in)
Housing Material: Plastic
Net Weight: 0.078kg (0.17lb)
Operating Temperature: 0°C - 70°C (32°F - 158°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
Humidity: 10 - 80% RH (non-condensing)
Power Requirements: 5VDC 1A
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 145x50x107mm (5.71x1.97x4.21in)
Gross Weight: 0.17kg (0.37lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH & California Proposition 65
Package Contents:

Phono to TosLink (Optical) & Coaxial ADC
USB Type A to DC Cable, 1m
Lindy Manual
Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

150m Cat.6 TosLink (Optical) & Coaxial Digital Audio Extender

Key Features:



Extends TosLink (Optical) & coaxial digital audio up to 150m over network cable
Supports stereo and multi-channel audio formats including Dolby Digital & DTS
Supports PoC (Power over Cat Cable) from the transmitter to receiver
Simultaneous audio output
2-year warranty


The Lindy 150m Cat.6 TosLink (Optical) & Coaxial Digital Audio Extender is a high-quality solution for extending digital audio signals over long distances, using standard network cable. With TosLink (Optical) and coaxial inputs and outputs, this extender can be easily used with a variety of AV source devices including TVs and amplifiers, with speakers or soundbars located at the receiver side.

Connected audio can be output simultaneously to provide splitting functionality from a single input, great for smaller audio broadcasting setups in underground railway stations, bus depots or medical facilities. This also allows simple conversion of TosLink and Coaxial signals into their opposing output.

Supporting both stereo and multi-channel audio extension, this extender will allow for impressive three-dimensional surround sound performance to compliment films and games when connected to the audio source device, as well as crystal clear speech from user generated audio. This provides the user with an excellent point to point solution, ideal for use in immersive residential cinema rooms or creating a more attractive and enticing retail experience.

PoC (Power over Cable) functionality, the supply of power and data signals over Cat.6 cable on a point-to-point connection between the transmitter and receiver also brings additional flexibility as only one power supply is required at the transmitter unit, ideal when power outlets are limited at the receiver end of the installation.

Please note: simultaneous output is only possible when identical 96KHz sample rates are used

Specifications:



AV Interface: Toslink (Optical), Coaxial
Maximum Distance: 150m (492.12ft)
Supported Audio: LPCM, Dolby Digital Digital, DTS
Separate Audio Ports: Toslink (Optical), Coaxial
Transmission Protocol: 1 x Cat.5e / 6
Chipset: EL5171/ EL5172
Special Features: PoC (Power over Cat Cable), Simultaneous Output*
Transmitter Input: Toslink (Optical) (Female), Coaxial (Female)
Transmitter Output: RJ-45 (Female)
Receiver Input: RJ-45 (Female)
Receiver Output: Toslink (Optical) (Female), Coaxial (Female)
Power : 5.5/2.1mm
Dimensions (approx.) WxDxH: 65.9x26.9x53.1mm (2.59x1.06x2.09in) per unit
Housing Material: Metal
Net Weight: 0.168kg (0.37lb)
Operating Temperature : 0°C - 50°C (32°F - 122°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
Humidity: 5% - 90% RH (non-condensing)
Power Requirements: 12VDC 1.25A
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 190x60x145mm (7.48x2.36x5.71in)
Gross Weight: 0.405kg (0.89lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS, REACH & California Proposition 65


Package Contents:



150m Cat.6 TosLink (Optical) & Coaxial Digital Audio Extender
Multi-country Power Supply (UK, EU, US & AUS)
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)
