Nuclias Connect AX1800 Wi-Fi 6 Access Point
The Wi-Fi 6 ready DAP-X2810 is on hand to provide unbeatable speeds, greatly increased capacity and interference-free coverage throughout businesses, paired with the easy management of Connect.
Product Features:
Easy to manage with D-Link’s free software-based management solution, Nuclias Connect
Wi-Fi 6 ready: delivers greater network efficiency and lower latency, with nearly four times the capacity of previous Wi-Fi standards
MU-MIMO slices through congestion, reducing wait time for all users
Superior throughput with dual-band Wi-Fi offers high transfer speeds of up to 1800 Mbps
Coverage is shared more efficiently over more users with Airtime Fairness
Band Steering intelligently manages users, pushing them onto the higher radio frequency when possible
Support for Power of Ethernet 802.3at means less wires, for cleaner and easier deployment
Stay secure with the latest WPA3 Personal & Enterprise wireless encryption
Take a Load Off and Let Your AP do the Hard Work
The DAP-X2810’s Load Balancing feature spreads the work load between two or more Access Points to get optimal resource utilization, throughput and response time, while Airtime Fairness helps distribute equal amounts of air time to each connected client. Band Steering auto-connects devices such as smart phones and tablets to the higher-capacity 5 GHz band while allowing devices 2.4 GHz-ready to remain. The result is a steady, consistent connection for each user – the perfect balancing act.
Product Features:One PoE Gigabit LAN port offers expansive backhaul to your wired network, eliminating bottlenecks at the AP
One RJ45 Console port for debugging
Supports multiple AP modes to ensure performance optimization based on your network’s needs (AP/WDS with AP/WDS)
MAC Address Filtering and WLAN Partitioning ensure ultimate control of your network’s access
Captive Portal with industry-standard authentication for enhanced access management
Works as a standalone AP or as part of a centralized, scalable multi-device deployment
Wi-Fi 6 Hails The End of Slow Business
The DAP-X2810 is empowered with next generation Wi-Fi 6. Enhanced MU-MIMO with even more uplink and downlink streams serves more devices simultaneously. OFDMA dramatically increases transmission efficiency and 1024-QAM packs even more data, bringing unadulterated speed increases of a searing 25%.
No-Wait Wi-Fi Even at Peak Time with MU-MIMO
Equipped with the latest 802.11ax MU-MIMO technology and 1800 Mbps throughput, delivering exceptional connectivity to more users and devices just got a lot easier. Your network will not balk, even at the busiest of times.
Free Nuclias Connect Remote Centralized Management Software
D-Link’s Nuclias Connect is a centralized management and analytics solution that brings convenience, control, customizability and cost-effective scaling to SMB (small-medium-sized business) networks. It enables network monitoring, management, and device configuration through a single, easy-to-use software interface.
The Beating Heart of Your Network
At the heart of your network is the DNH-100 Wireless Controller, or ‘The Hub’. It centralizes all aspects of your Access Points’ provisioning and management, allowing them to work together as a team. Features such as self-organizing, self-optimizing and self-healing keep the network performing at its peak.
Multi-Mode Makes the Most of your Network Capabilities
In order to achieve optimal network performance, the DAP-2682 has several operational modes tailored to best fit the individual needs of your network. Access Point, Wireless Client, WDS (Wireless Distribution System), and WDS with Access Point modes allow for flexible, customizable deployment whatever your requirements.
Access Point
Add wireless access to your existing wired network.
WDS
Wirelessly connect two separate networks.
WDS with AP
Wirelessly connect two separate networks while also providing wireless access to both networks.
Product Features:
Easy to manage with D-Link’s free software-based management solution, Nuclias Connect
Wi-Fi 6 ready: delivers greater network efficiency and lower latency, with nearly four times the capacity of previous Wi-Fi standards
MU-MIMO slices through congestion, reducing wait time for all users
Superior throughput with dual-band Wi-Fi offers high transfer speeds of up to 1800 Mbps
Coverage is shared more efficiently over more users with Airtime Fairness
Band Steering intelligently manages users, pushing them onto the higher radio frequency when possible
Support for Power of Ethernet 802.3at means less wires, for cleaner and easier deployment
Stay secure with the latest WPA3 Personal & Enterprise wireless encryption
Physical
Max. Power Consumption
14.7 W by ADP, 16 W by PoE
Power Supply
12 V / 2.5 A (optional power adapter), IEEE 802.3at PoE
Operating Temperature
0 ?C to 40 ?C / 32 ?F to 104 ?F
Temperature (Storage)
-20?C to 65 ?C / -4 ?F to 149?F
Humidity (Operating)
10% to 90% non-condensing
Humidity (Storage)
5% to 95% non-condensing
Dimensions
170 x 170 x 33.7 mm / 6.69 x 6.69 x 1.3 in
Weight
477.4 g / 1.05 lb
General
Device Interfaces
1 x RJ45 console port, 1 x 10/100/1000 Ethernet / (PoE) LAN, factory reset, power input
LEDs
Power / Status
Antennas
2 x dual-band internal antennas
Antenna Gain
3.2 dBi (2.4 GHz), 4.3 dBi (5 GHz)
Maximum Output Power
23 dBm (2.4 GHz), 26 dBm (5 GHz)
Data Signal Rate
Up to 1800 Mbps
Full specification and details can be found in the
Nuclias Connect AX3600 Wi-Fi Access Point
The Wi-Fi 6 ready DAP-X2850 is on hand to provide unbeatable speeds, greatly increased capacity and interference-free coverage throughout businesses, paired with the easy management of Connect.
Product Features:
Easy to manage with D-Link’s free software-based management solution, Nuclias Connect
Wi-Fi 6 ready: delivers greater network efficiency and lower latency, with nearly four times the capacity of previous Wi-Fi standards
MU-MIMO slices through congestion, reducing wait time for all users
Superior throughput with dual-band Wi-Fi offers high transfer speeds
Coverage is shared more efficiently over more users with Airtime Fairness
Band Steering intelligently manages users, pushing them onto the higher radio frequency when possible
Two LAN ports (2.5 Gbps and 1 Gbps) offer expansive backhaul up to wired network, eliminating bottlenecks at the AP
Support for Power of Ethernet 802.3at means less wires, for cleaner and easier deployment
Stay secure with the latest WPA3 Personal & Enterprise wireless encryptio
Take a Load Off and Let Your AP do the Hard Work
The DAP-X2810’s Load Balancing feature spreads the work load between two or more Access Points to get optimal resource utilization, throughput and response time, while Airtime Fairness helps distribute equal amounts of air time to each connected client. Band Steering auto-connects devices such as smart phones and tablets to the higher-capacity 5 GHz band while allowing devices 2.4 GHz-ready to remain. The result is a steady, consistent connection for each user – the perfect balancing act.
Product Features:Supports multiple AP modes to ensure performance optimization based on your network’s needs
MAC Address Filtering and WLAN Partitioning ensure ultimate control of your network’s access
Captive Portal with industry-standard authentication for enhanced access management
Works as a standalone AP or as part of a centralized, scalable multidevice deployment
Wi-Fi 6 Hails The End of Slow Business
The DAP-X2810 is empowered with next generation Wi-Fi 6. Enhanced MU-MIMO with even more uplink and downlink streams serves more devices simultaneously. OFDMA dramatically increases transmission efficiency and 1024-QAM packs even more data, bringing unadulterated speed increases of a searing 25%.
No-Wait Wi-Fi Even at Peak Time with MU-MIMO
Equipped with the latest 802.11ax MU-MIMO technology and 1800 Mbps throughput, delivering exceptional connectivity to more users and devices just got a lot easier. Your network will not balk, even at the busiest of times.
Your Network, Future Proofed
Equipped with a 2.5 Gigabit Ethernet Port, the DAP-X2850 delivers exceptional multi-gigabit performance to support demand for better and faster Wi-Fi. Compatibility with standard 802.3at PoE+ is ideal for flexible deployment. No need to run extra power lines, no added hassle when configuring your hardwiring and no more cable clutter. Perfect for advanced installations in areas where power outlets are not readily available.
Free Nuclias Connect Remote Centralized Management Software
D-Link’s Nuclias Connect is a centralized management and analytics solution that brings convenience, control, customizability and cost-effective scaling to SMB (small-medium-sized business) networks. It enables network monitoring, management, and device configuration through a single, easy-to-use software interface.
The Beating Heart of Your Network
At the heart of your network is the DNH-100 Wireless Controller, or ‘The Hub’. It centralizes all aspects of your Access Points’ provisioning and management, allowing them to work together as a team. Features such as self-organizing, self-optimizing and self-healing keep the network performing at its peak.
Multi-Mode Makes the Most of your Network Capabilities
In order to achieve optimal network performance, the DAP-2682 has several operational modes tailored to best fit the individual needs of your network. Access Point, Wireless Client, WDS (Wireless Distribution System), and WDS with Access Point modes allow for flexible, customizable deployment whatever your requirements.
Access Point
Add wireless access to your existing wired network.
WDS
Wirelessly connect two separate networks.
WDS with AP
Wirelessly connect two separate networks while also providing wireless access to both networks.
Physical
Max. Power Consumption
19.44 W
Power Supply
12 V / 2.5 A (optional power adapter), IEEE 802.3at PoE
Operating Temperature
0 ?C to 40 ?C / 32 ?F to 104 ?F
Temperature (Storage)
-20?C to 65 ?C / -4 ?F to 149?F
Humidity (Operating)
10% to 90% non-condensing
Humidity (Storage)
5% to 95% non-condensing
Dimensions
212.4 x 212.4 x 46.7 mm / 8.36 x 8.36 x 1.8 in
Weight
763.8 g / 1.7 lb
General
Device Interfaces
1 x RJ45 console port, 1 x 2.5 Gbps Ethernet / LAN (PoE), 1 x 10/100/1000 Mbps Ethernet / LAN, factory reset, power input
LEDs
Power / Status
Antennas
4 x internal
Antenna Gain
3.5 dBi (2.4 GHz), 5.5 dBi (5 GHz)
Maximum Output Power
28 dBm (2.4 GHz), 25.5 dBm (5 GHz)
Data Signal Rate
Up to 3600 Mbps
Full specification and details can be found in the
Next-Generation Wi-Fi 6
The AX3600 Wi-Fi 6 Dual-Band Unified Access Point brings the latest Wi-Fi technology to small-to-medium-sized businesses as well as larger enterprises. It's part of D-Link's Unified Wireless solution that allows companies to set up a highly scalable, flexible and manageable Wi-Fi network.
Key Features
802.11ax Wi-Fi CERTIFIED 6™, Dual-Band, up to 3.6 Gbps
4x4 MU-MIMO internal omnidirectional antennas
Self-optimising, self-healing, Fast Roaming with wireless controller
Link Aggregation with 2.5G and Gigabit ports
Limited Lifetime Warranty with registration
Wi-Fi 6
Next-generation 802.11ax Wi-Fi CERTIFIED 6™ technology provides increased speed, capacity and the latest WPA3 security.
4 x 4 MU-MIMO
Improved efficiency in handling throughput distribution to multiple devices connected to the network.
Dual-Band with band steering
Two bands to improve throughput and coverage as well as reduces co-channel interference.
Fast roaming
Allows wireless clients to move freely, jumping from AP to AP without losing connectivity.
PoE & flexible installation
Power the device over Ethernet without the need for nearby power outlets with the option for ceiling or wall mounting.
Centrally Managed
Used as a standalone wireless access point or managed centrally via a D-Link Wireless Controller.
Self-healing
Set up a robust and resilient wireless network that can automatically heal itself when an AP fails.
Limited Lifetime Warranty & Next Day Service
Register to enjoy D-Link Limited Lifetime Warranty support, with complimentary next business day advance replacement service included.
Take Your Business to the Next Level with Wi-Fi 6
Uses the latest Wi-Fi technology to deliver reliable wireless performance and reduce congestion, with combined maximum wireless signal rates of up to 3.6 Gbps (1147 Mbps on 2.4 GHz band and 2402 Mbps on 5 GHz band).
Together with OFDMA and MU-MIMO support, the DWL-X8630AP gives your business a faster wireless network with higher capacity and efficiency.
Band steering
MU-MIMO
Airtime Fairness
802.11k Fast Roaming
Flexible Installation
Power-over-Ethernet support allows the DWL-X8630AP to be connected and powered using a single cable, so it can be installed in areas without power outlets.
Highly Scalable and Centrally Managed
The DWL-X8630AP can be used as a single access point or as part of a centrally managed wireless network with up to 1,024 access points when deployed with D-Link Unified Wireless Controllers.
Self-Healing and Resilient
When working in conjunction with D-Link Unified Wireless Controllers, you can create a network that automatically heals itself when an access point or controller fails, allowing your business to stay online.
Self-Optimised Network
Automatic radio frequency (RF) management provides the best possible coverage for wireless clients by reducing interference when access points are deployed close to each other. When the DWL-X8630AP senses a neighbouring AP nearby, it will automatically select a non-interfering channel.
This significantly reduces RF interference and allows you to deploy APs more densely. To further minimise interference, when a nearby AP is on the same channel, the DWL-X8630AP will automatically adjust its transmission power.
D-Link is officially Wi-Fi Certified by the Alliance
The Wi-Fi CERTIFIED 6™ seal is a declaration of having passed a series of rigorous tests performed by the Wi-Fi Alliance - an internationally recognised organisation. It's only granted to products that adhere to the strict industry-agreed standards for interoperability.
With this, purchasing a D-Link Wi-Fi CERTIFIED 6™ device ensures increased speeds, advanced Wi-Fi 6 capability, backwards compatibility and improved security.
Free Next-Business-Day Service
Enjoy our free Next Business Day service, as standard, to replace faulty equipment quickly.
Our rapid-response technical support is designed to ensure businesses get the best support for their unique environment. Our extended warranty and enhanced service packages increase the lengths of warranties and further minimises downtime. You can even opt for our Same Business Day Service which guarantees the delivery of the replacement product within 4 hours of confirmation of product failure.
AX1800 Wi-Fi 6 Cloud-Managed Access Point
The Wi-Fi 6 ready Nuclias Cloud access point provides enhanced wireless speeds, greatly increased capacity and interference-free coverage throughout businesses
Main features:
Centralised cloud-based management via browser & app
Dual-band Wi-Fi 6 speeds of up to 1.8Gbps
Band Steering with Airtime Fairness & MU-MIMO
Power over Ethernet 802.3at
Zero-Touch Deployment with plug & play installation
WPA3 encryption
Network management has never been this easy
Business-class Wi-Fi 6. Manage your wireless network from anywhere in the world with the Nuclias AX1800 Wi-Fi 6 Cloud-Managed Access Point. Designed to give you the latest technology and efficiency in any setup, it’s ideal for SMB, retailers, hospitality, campuses, and managed service provider.
Exceptional connectivity, exceptional performance
With combined Wi-Fi 6 speeds of up to 1,800 Mbps with MU-MIMO and dual-band technology, The DBA-X1230P provides lightning-fast access to cloud-based applications, fast data transfer, smooth voice and video streaming, even in highly congested environments.
A more effective and efficient network
When multiple access points are deployed in the same location, Nuclias Cloud supports automatic load balancing between them without the need for additional hardware or configuration. This ensures the Wi-Fi network performs optimally, all the time. And BSS Colouring, OFDMA, and MU-MIMO all increase wireless network capacity and efficiency.
Exceptional connectivity, exceptional performance
With combined Wi-Fi 6 speeds of up to 1,800 Mbps with MU-MIMO and dual-band technology, The DBA-X1230P provides lightning-fast access to cloud-based applications, fast data transfer, smooth voice and video streaming, even in highly congested environments.
Get your networks up and running from anywhere, easily and quickly
The DBA-X1230P can be deployed without the need to send IT engineers on-site. With Nuclias Cloud’s Zero Touch Provisioning, you can power-up the access points on site, connect them to the network, and remotely set up and manage them through the Nuclias Cloud portal.
Your Guests Online in No Time with a Captive Portal
Get your guests online quickly and easily with a captive portal. Not only can you let them connect using just their email address, Facebook or Google account, it also gives your business the opportunity to increase brand awareness and advertise promotions. At the same time, it can provide user insights that allow businesses to better understand their customers.
Scale your Wi-Fi alongside your business
Nuclias Cloud is designed with unlimited scalability, so you can always tailor to the demands of your business. Adding a new site or expanding an existing one is quick and easy as all management and configuration is done through the cloud, with access points being ready to deploy straight out of the box.
Complete Control over your Network
With D-Link Nuclias Cloud, businesses can organise their entire wireless network, manage multiple APs simultaneously, and monitor live network statistics. Now you can focus more on providing reliable connectivity and services and spend less time managing devices.
• Intuitive app
• Real-time network information
• Manage multiple sites and devices
• Over-the-air firmware updates
Nuclias Connect provides centralised cloud-based management, with intuitive web and app-based interface (1-year license included)
Wi-Fi 6 ready: delivers greater network efficiency and lower latency, with nearly four times the capacity of previous Wi-Fi standards
MU-MIMO slices through congestion, reducing wait time for all users
BSS Coloring enables wireless networks to more effectively transmit data to multiple devices by identifying Overlapping Basic Service Sets (OBSS) to eliminate medium contention
Superior throughput with dual-band Wi-Fi offers high transfer speeds
• Coverage is shared more efficiently over more users with Airtime Fairness
• Band Steering intelligently manages users, pushing them onto the higher radio frequency when possible
Support for 802.3at Power of Ethernet means fewer wires and easier deployment
With Zero Touch Deployment, swift plug and play installation eliminates the need for on-site setup
Stay secure with the latest WPA3 Personal & Enterprise wireless encryption
Physical
Dimensions
170 x 170 x 42.2 mm
Weight
484 g (without mount)
Power Input
IEEE 802.3at Power over Ethernet (PoE) / Power Adapter : 12V/ 1.5A (not included)
Power Consumption
PoE: 14 W / Power adapter: 16 W
Temperature (Operating)
0 to 40 °C
Temperature (Storage)
-20 to 65 °C
Humidity (Operating)
10% to 90% non-condensing
Humidity (Storage)
5% to 95% non-condensing
Mean Time Between Failure (MTBF)
1,037,000 hours
General
Interfaces
IEEE 802.11ax Wi-Fi 6 / IEEE 802.11a/b/g/n/ac Wave 2 wireless / 1 x 10/100/1000 Mbps Ethernet Port / 1 x RJ45 Console port
Standards
IEEE 802.11a/b/n/g/ac/ax / IEEE 802.3az Energy-Efficient Ethernet (EEE) / IEEE 802.3at Power over Ethernet (PoE) / IEEE 802.3i/u/ab / IEEE 802.3x Flow Control
LEDs
Power/Cloud
Antenna
2 x 2 Internal omni-directional antennas (2.4 GHz: 3 dBi, 5 GHz: 4 dBi)
Full specification and details can be found in the
Cloud-managed Wi-Fi 6
The Wi-Fi 6-ready DBA-X2830P access point is on hand to provide unbeatable speeds, greatly increased capacity and interference-free coverage throughout businesses.
Features
Centralized cloud-based management, with intuitive web and app-based interface
Wi-Fi 6 ready: delivers greater network efficiency and lower latency, with nearly four times the capacity of previous Wi-Fi standards
4 x 4 MU-MIMO slices through congestion, reducing wait time for all users
Superior throughput with dual-band transfer speeds of up to 1147 Mbps in the 2.4 GHz band and 2402 Mbps in the 5 GHz band
Coverage is shared more efficiently over more users with Airtime Fairness
Band Steering intelligently manages users, pushing them onto the higher radio frequency when possible
Two LAN ports capable of Link Aggregation offer 3.5 Gbps of backhaul up to the wired network, eliminating bottlenecks at the AP
Support for Power over Ethernet 802.3at means less wires, for cleaner and easier deployment
With Zero Touch Deployment, swift plug and play installation eliminates the need for on-site setup
Supports WPA3™ - the latest Wi-Fi encryption standard for even more protection
Peak Performance and Discreet Deployment with Power over Ethernet (PoE)
The DBA-X2830P's Power over Ethernet function allows for easy installation and a simple, clean setup. No need to run extra power lines, no added hassle when configuring your hardwiring and no more cable clutter. Perfect for advanced installations in areas where power outlets are not readily available.
- Review: The 10 Best Wireless Access Points
- Review: The Top 10 Best Ethernet Cables
- What Is An Ethernet Cable And What Does It Do?
- 10 Best CCTV Security IP Cameras For Home & Business
- Review: Best Powerline Adapters In The UK
- Celebrating 20 Years Of Comms Express!
- The Top 10 DrayTek Wireless Access Points
- Best Selling APC Products At Comms Express
- Review: Top 5 Best Performing APC Uninterruptible Power Supply Units (UPS)
- Review: Top 10 Best PDU’s
