CyberPower PDU44004 provides output from a UPS unit, generator, or utility power to multiple connected devices in IT environments. Dual power cords can be plugged into separate power sources to provide redundancy to single-corded connected equipment. If the selected power source exceeds the desired thresholds or fails, the ATS PDU will automatically switch to the other power source within 10 ms (Source Failure Detection Time: 2-3 ms. Power Source Transfer Time: 2-7 ms) to ensure continuous operation. The unit supports remote individual outlet control over the network, allowing administrators to turn on/off connected devices from any location.
The product is built-in with hot-swappable Ethernet module, which can work with PowerPanel Power Management Software and power management web interface for real-time remote monitoring and configuration. The digital LCD display is also color configurable, allowing users to easily maintain and monitor the ATS PDU. Users can change LCD's colors to easily categorize devices between multiple machines in server room and IT environments. Event logging via a web browser or network connection allows users to review the history of power conditions. When specified power events occur, automatic event notifications will be sent via email, SMS text, or SNMP trap to designated users so that they can take immediate actions. The USB port also supports easy firmware upgrade. Moreover, the featured RJ45 port enables the connection of the optional environmental sensor (ENVIROSENSOR), which can provide real-time temperature and humidity monitoring in an IT center.
Specifications
Type
Voltage (Vac)
Rated Current (A)
Outlet Type
Installed Rack Height (U)
Switched
200 ~ 240
12 (UL)
10 (CE)
IEC C13 x 12
1
Main Features
Real-time Local Monitoring
Dual Inputs
Quick Transfer Time (Total < 10 ms)
Controllable Receptacles With Power Sequencing
Industrial-grade Metal Housing
User Configurable Color LCD
LED Status Indicator
Support ENVIROSENSOR
PowerPanel Management Software
Cord Retention Tray
Digital Real-time Load Display
Hot-swappable LCD Design
Firmware Upgrade via USB
User-upgradeable Firmware
Adjustable Mounting Brackets
IEC Receptacle Locking
Box Contents
1. PDU44004
2. User's Manual
3. Cord Retention Tray
4. Mounting Brackets
5. Cable Ties
6. Screw Kit
7. Power Cord
8. Serial Cable
* Product contents may vary according to different regions. For detailed information, please refer to user's manual/quick start guide.
