Unleash Long-Range WiFi Power with the Ubiquiti UniFi UAP-AC-LR Access Point (5-Pack) - UAP-AC-LR5
Conquer large spaces and extend your wireless network effortlessly with the Ubiquiti UniFi UAP-AC-LR Access Point (5-Pack) - UAP-AC-LR5. This value bundle delivers five powerful access points designed for long-range deployments, making it ideal for offices, schools, warehouses, and any environment requiring extensive WiFi coverage.
The UniFi AC LR AP features the latest Wi-Fi 802.11ac technology in a refined industrial design and is ideal for long-range deployment of high-performance wireless networks.
Features:
Innovative Antenna Design
The innovative antenna design provides a long-range, symmetrical-link coverage area, and the antenna gain of the UniFi AC LR AP performs better than one-way, high transmit power does for connecting distant clients.
Designed for Optimal RF Performance
The newly redesigned UniFi Controller optimises RF performance:
| Spectral Analysis | Band Steering | Air Fairness |
| Collects feedback on full 5GHz & 2.4 GHz channel interference | Pushes clients to faster interference-free, 5GHZ channels | Minimises problem-client effects in system performance by limiting their airtime access |
Scalable Enterprise Wi-Fi Management
The UniFi Controller v4 software is a powerful, enterprise wireless software engine ideal for high-density client deployments requiring low latency and high uptime performance. With its software-based capabilities, the UniFi virtual control plane allows for unlimited scalability under one centralised controller. Remotely access the UniFi Controller to upgrade deployed UniFi APs while in the field.
Access Point Comparison Chart
 |
UAP-AC-IW | UAP-AC-IW-PRO | UAP-AC-LITE | UAP-AC-LR | UAP-AC-PRO | UAP-AC-HD |
| Environment | Indoor | Indoor | Indoor | Indoor | Indoor/ Outdoor | Indoor/Outdoor (covered) |
| Simultaneous Dual-Band |  |
|
|
|
|
|
| 2.4 GHz Speed | 300 Mbps | 450 Mbps | 450 Mbps | 450 Mbps | 450 Mbps | 800 Mbps |
| 2.4 GHz MIMO | 2x2 | 3x3 | 3x3 | 3x3 | 3x3 | 4x4 |
| 5 GHz Speed | 867 Mbps | 1300 Mbps | 867 Mbps | 1300 Mbps | 1300 Mbps | 1733 Mbps |
| 5 GHz MIMO | 2x2 | 3x3 | 2x2 | 3x3 | 3x3 | 4x4 |
| Range | 183 mt | 122 mt | 183 mt | 122 mt | ||
| Secondary Ethernet Port | (2 Additional Ports) |
(2 Additional Ports) |
|
|
||
| PoE Mode | 802.3at PoE+ | 802.3at PoE+ | 802.3af/A PoE 24V Passive PoE |
802.3af/A PoE 24V Passive PoE |
802.3af PoE 802.3at PoE+ |
802.3at PoE+ |
| Ceiling Mount | |
|
|
|
||
| Wall Mount | |
|
|
|
|
|
| Wireless Uplink | |
|
|
|
|
|
| DFS Certification | |
|
|
|
|
|
| Dimensions(mm) | 140 x 87 x 26 | 140 x 87 x 26 | 160 x 31.5 | 176 x 43 | 197 x 35 | 220 x 48 |
* Please note that the multi-pack does not include PoE adapters.
Ubiquiti Extended Warranty
Ubiquiti currently offers 1 year standard manufacturer warranty on equipment purchased through official UK distributors.
In the unlikely event that you have any issues with your Ubiquiti product within the 1 year of manufacturer warranty, please contact your account manager in the first instance. Our technical team will do everything they can to find a resolution to your problem. If a fix cannot be provided, then an RMA will need to be registered via the Ubiquiti Reseller Portal.
On all purchases made through Comms Express, we offer our customers options to upgrade the standard manufacturer warranty to a 3 or 5 year advanced hardware replacement.
Available warranty options:
The innovative antenna design provides a long-range, symmetrical-link coverage area, and the antenna gain of the UniFi AC LR AP performs better than one-way, high transmit power does for connecting distant clients.
The newly redesigned UniFi Controller optimises RF performance:
Spectral Analysis
Collects feedback on full 5GHz & 2.4 GHz channel interference
Band Steering
Pushes clients to faster interference-free, 5GHZ channels
Airtime Fairness
Minimises problem-client effects in system performance by limiting their airtime access
The UniFi Controller v4 software is a powerful, enterprise wireless software engine ideal for high-density client deployments requiring low latency and high uptime performance. With its software-based capabilities, the UniFi virtual control plane allows for unlimited scalability under one centralised controller. Remotely access the UniFi Controller to upgrade deployed UniFi APs while in the field.
