| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | TLSR14UBDP |
| Manufacturer No: | SR14UBDP |
| Delivery: | Out Of Stock |
 |
14U SmartRack Extra Deep Small Server Rack Enclosure, Doors & Side Panels Included
14U rack cabinet houses, organizes and secures deeper standard-width rack equipment in high-density server and IT networking areas
Features
This SmartRack® 14U rack enclosure is designed for network wiring closets, retail locations, classrooms, back offices and other areas with essential rack-mount IT equipment. It supports mounting of equipment up to 42 inches deep. This allows high-density equipment installations, extra space for cable management, and room for removing hot-swap power supplies from the rear of mounted devices. Constructed from heavy-duty steel with a durable black powder-coated finish, the SR14UBDP has a maximum load capacity of 1000 lbs (453.6 kgs).
The reversible front and rear doors and removable side panels lock securely to help prevent damage, tampering or theft. The doors, side panels and top panel are designed for quick release, making it easy to access connected equipment and cabling with little effort. Convenient top access ports and an open bottom allow easy cable routing through the cabinet. The vented doors draw in cool air from outside and remove warm air to keep your equipment cool and functioning at their peak. The top panel also supports the installation of optional case fans (such as Tripp Lite's SRFANWM).
This 14U server rack comes fully assembled for quick and easy deployment. Four metal casters (and installation hardware) are included that let you maneuver the rack cabinet over a level, smooth, stable surface and through a standard doorway into position, where it can be stabilized by adjusting the levelers. Front and rear mounting rails adjust in quarter-inch increments to accommodate equipment up to 42 inches deep. Adjustable vertical cable management rails help keep the back of the rack organized.
The SR14UBDP provides physical equipment and media security required for PCI DSS (Payment Card Industry Data Security Standard) compliance. This is essential for companies that process, store and/or transmit credit card information.
Typical Applications
Package Includes
| Overview | |
| UPC Code | 037332197917 |
| Device Compatibility | Patch Panel; Network Switch; UPS; Server |
| Rack Type | Enclosure |
| Physical | |
| Colour | Black |
| Factory Preset Rack Depth | 71.9 cm / 719 mm |
| Maximum Device Depth | 93.98 cm / 940 mm |
| Minimum Device Depth | 7.62 cm / 76 mm |
| Rack Height | 14U |
| Shipping Dimensions (height x width x depth) | 85.22 x 65.71 x 116.79 cm |
| Shipping Weight | 70.76 kg |
| Unit Dimensions (height x width x depth) | 71.70 x 60 x 110.80 cm |
| Unit Weight | 47.63 kg |
| Weight Capacity - Rolling | 454 kg |
| Weight Capacity - Stationary | 454 kg |
| Rack Depth | Standard |
| Number of Vertical Mounting Rails | 4 |
Full specification and details can be found in the PDF file
