    StarTech FAN8025PWM 80x25mm Computer Case Fan with PWM

    80x25mm Computer Case Fan with PWM – Pulse Width Modulation Connector

    Add a Variable Speed, PWM-Controlled Cooling Fan to a Computer Case






    The FAN8025PWM 80mm PWM Case Fan adds an efficient air cooling solution to computer cases or other enclosures, to keep components running optimally.


    With Pulse Width Modulation (PWM) technology, the fan speed can be dynamically controlled by the motherboard, so the fan runs at a speed that suits the operating conditions - lowering power consumption and fan noise when the system is idle, and delivering maximum cooling under full load conditions.


    Backed by a StarTech.com 2-year warranty and free lifetime technical support.



    Applications:

    • Lowering power consumption and fan noise on computer systems where the cooling fan does not need to run at full speed all the time
    • Noisy or failed case fan replacement/upgrade
    • Add an extra fan to a computer for improved system cooling


    Features:

    • 4-pin Pulse Width Modulation (PWM) motherboard connector
    • Ever Lubricate Bearing design
    • Includes a PWM Y-split cable


    The StarTech.com Advantage:

    • PWM control enables the fan to be controlled by the motherboard according to current system requirements, ensuring optimal system performance
    • Ever Lubricate bearing design increases reliability and lifespan over fans with a traditional sleeve bearing design
    • Backed by a StarTech.com 2-year warranty and free lifetime technical support




    Performance
    Noise level (high speed) 28 dB
    Type Fan
    Suitable for Computer case
    Operating temperature (T-T) -10 - 70 °C
    Fan diameter 8 cm
    Mean time between failures (MTBF) 40000 h


    Design
    Material Plastic
    Product colour Black


    Technical details
    Noise level (high speed) 28 dB
    Type Fan
    Suitable for Computer case
    Fan diameter 8 cm
    Material Plastic
    Connector(s) 1 - Molex Fan (4 pin; PWM)


    Power
    Voltage 12 V
    Rated current 0.16 A


    Operational conditions
    Operating temperature (T-T) -10 - 70 °C
    Operating relative humidity (H-H) 0 - 65%
    Storage relative humidity (H-H) -20 - 70%


    Weight & dimensions
    Package width 96 mm
    Package height 32 mm
    Package depth 143 mm
    Package weight 111 g
    Weight 86 mm


    Other features
    Operating relative humidity (H-H) 0 - 65%
    Storage relative humidity (H-H) -20 - 70%
    Fan performance 25.02 cfm
    Rotational speed 2500 RPM
    Dimensions (WxDxH) 80 x 80 x 25 mm
    Connector(s) 1 - Molex Fan (4 pin; PWM)

    Full specification and details can be found in the PDF file

    A user manual can be found in the PDF file
