| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | FECDP2DP141MB |
| Manufacturer No: | CDP2DP141MB |
| Delivery: | In Stock: Next Day |
 |
3.3ft/1m USB C to DisplayPort 1.4 Cable - 8K/5K/4K USB Type-C to DP 1.4 Alt Mode Video Adapter Converter - HBR3/HDR/DSC - 8K 60Hz DP Monitor Cable - USB-C/Thunderbolt 3
USB-C™ Video Adapter Cable | Thunderbolt™ 3 Compatible | HBR3
This USB-C to DisplayPort 1.4 cable lets you connect your USB Type-C device to a DisplayPort monitor with just one cable, providing you with a convenient, clutter-free solution.
Supporting four times the resolution of 4K, this 8K DP 1.4 adapter cable delivers the stunning quality of UHD at resolutions up to 7680×4320, and also features HBR3 functionality, providing a bandwidth of up to 32.4Gbps.
With cutting-edge picture quality, this cable is ideal for:
• Displaying crisp digital signage walls
• Creating eye-catching visuals for photography and videography
The USB-C to DP cable is backward compatible with 4K and 1080p displays, which makes it a great accessory for home, office or other work environments, while future-proofing for 8K implementation.
At 3.3 ft. (1 m) in length, this DisplayPort adapter cable delivers a compact connection that eliminates excess cabling, ensuring a tidy installation. For installations requiring a longer length, we also offer a 6 ft. (1.8 m) DisplayPort cable, enabling you to customize your connection needs.
To ensure easy operation, this DisplayPort converter cable supports plug-and-play installation, removing the need for additional software or drivers.
To ensure easy operation, this DisplayPort converter cable supports plug-and-play installation, removing the need for additional software or drivers.
Note:
• Your USB-C device must support DP Alt Mode to work with this adapter cable
• To achieve 8K resolutions, your source and your destination must support DisplayPort 1.4
| Features | |
| Chipset | STM32F072CBY6TR |
| DisplayPort version | 1.4 |
| Product colour | Black |
| Connector 1 | DisplayPort |
| Connector 2 | USB Type-C |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Bandwidth | 32400 MB/s |
| Maximum resolution | 7680 x 4320 pixels |
| Supported graphics resolutions | 1024 x 768 (XGA),1280 x 720 (HD 720),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),2560 x 1440,2560 x 1600 (WQXGA),3840 x 2160,4096 x 2160,7680 x 4320 |
| HDCP | Yes |
| Certification | CE, FCC, REACH |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Maximum refresh rate | 120 Hz |
| HDCP version | 1.4/2.2 |
| High Dynamic Range (HDR) supported | Yes |
| Supported audio channels | 7.1 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 80 - 90% |
| Weight & dimensions | |
| Width | 200 mm |
| Depth | 11 mm |
| Height | 1000 mm |
| Weight | 38 g |
| Cable length | 1 m |
| Logistics data | |
| Master (outer) case width | 50 cm |
| Master (outer) case length | 33 cm |
| Master (outer) case height | 22 cm |
| Quantity per master (outer) case | 90 pc(s) |
Full specification and details can be found in the PDF file
A product diagram can be found in the PDF file
