| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | CA-URSH360 |
| Manufacturer No: | 122-2413 |
| Delivery: | In Stock: 1-2 Days |
 |
Features
This slide rail kit allows the HP DL360 Gen 8 to be installed in any type of server rack. These rails replace the HP rail kit that would normally come with the server. This DL360 Gen 8 rail kit allows the server to be installed in typical 4Post server racks as well as 2Post server racks. These rails are considered a dry slide type. They allow the server to slide in and out, but they are not ball bearing slides. Also, the rails do not include a stop catch mechanism that prevents the server from sliding completely out of the rack when removing it for servicing.
Fits any 4 Post, 2 Post racks
Alternative to HP DL360 Gen 8 rail kit
Technical Specifications
|
Rail OEM |
HP |
|
Server Compatibility |
HP DL360 Gen 8 |
|
Rack Type |
4Post, 2Post |
|
Hole Type |
Square, round, threaded |
|
Rail Type |
Non-ball bearing slides |
|
Rack Units |
|
|
Mounting Depth Range |
4Post server racks: 18 - 34.5" (457 - 876 mm) |
|
Included Hardware |
Mounting Hardware: |
|
Finish |
Zinc plated |
|
Tech Notes |
This rail kit replaces the HP rail kit in installations where the HP rail kit is incompatible with the existing server rack |
| Specifications | |
| Rail OEM | HP |
| Server Compatibility | HP DL360 Gen 8 |
| Rack Type | 4Post, 2Post |
| Hole Type | Square, round, threaded |
| Rail Type | Non-ball bearing slides |
| Rack Units | 1U |
| Mounting Depth Range | 4Post server racks: 18 - 34.5" (457 - 876 mm) |
| Finish | Zinc plated |
| Included Hardware | Mounting Hardware (8) 8-32 x .500 Pan Head Screws (2) Retainer Plate (Left & Right) (2) Mounting Plate (8) 10-32 x .500 Pan Head Screws (8) 12-24 x .500 Pan Head Screws (8) 12-24 Square Nut (8) 12-24 Cage Nut Rear Bracket Hardware (4) 8-32 x .375 Flat Head Screws (4) 8-32 Keps Nuts |
| Tech Notes | This rail kit replaces the HP rail kit in installations where the HP rail kit is incompatible with the existing server rack |
