From the Lines cable connectivity concept developed by Lindy, Gold Line DVI-D Single Link cables are the no compromise, high performance connection solution for use in the most demanding professional environments.
These superior quality cables utilise a unique low attenuation design that ensures consistent and reliable transmission even over very long distances.
For complete signal integrity, Gold Line DVI-D Single Link cables feature 24K gold plated contacts, triple shielding with 100% aluminium mylar wrap and an 85% tinned copper braid.
Gold Line DVI-D Single Link cables support DVI resolutions up to 1920x1200@60Hz including HD resolutions up to 1080p.
Gold Line DVI-D Single Link cables are available in lengths from 10m to 25m.
Features
Technical Information
| Connectors | |
| Connector A | DVI-D Male (Single Link) |
| Connector B | DVI-D Male (Single Link) |
| Housing Material | 24K Gold Plated Metal |
| Connector Plating | 24K Gold 3µm |
| Pin Construction | Phosphor Bronze |
| Pin Plating | 24K Gold 15µm |
|
Dimensions (approx.) WxDxH |
39.5x16.5x44.5mm (1.55x0.65x1.73in) |
| Cable Construction | |
| Lengths Available | 10m, 15m and 20m |
| Colour | Grey |
| Standard | DVI-D Single Link |
| Jacket Diameter | 9mm (0.35in) |
| Jacket Material | PVC |
| Conductor Material | OFC Copper |
| Conductor Gauge | 24AWG |
| Type | Round |
| Shielding | Copper Braid 85% |
| Specifications | |
| Supported Bandwidth | 4.95 Gbit/s |
| Maximum Resolution | 1920x1200@60Hz |
| Nominal Attenuation: | 1 - 825Mhz < 8db |
| Minimum Bend Radius | 126mm (4.96in) |
| Operating Temperature | -20°C - 80°C |
| Storage Temperature | -25°C - 85°C |
