Lindy 32121 VGA EDID Emulator

VGA EDID Emulator

Key Features:

• Continuously emulates VGA EDID information
• Supports resolutions up to 1920x1200@60Hz
• For use with 32120 for cloning
• Powered via VGA Source Interface, 3.5/1.35mm Optional DC jack for non-powered source devices
• 2 Year warranty

The Lindy VGA EDID Emulator is designed for systems that require EDID signals to be continuously provided without interruption and helps overcome EDID related problems which can occur when using AV/KVM extenders, switches and splitters. It can also be used in place of a monitor to keep the graphics card of a PC or server awake for remote access via IP. With support for resolutions up to 1920x1200@60Hz, the emulator is suitable for use with legacy PCs and displays. When used with the Lindy EDID recorder (32120) this device can provide cloned EDID information to the graphics card.

It is also possible to use the Emulator without cloning a display as it comes complete with pre-set EDID data for the most commonly used resolution/timing combinations, please see the Technical Information section for a full breakdown.

Specification:

• AV Interface: VGA
• Interface Standard: VGA
• Supported Bandwidth: 4.95Gbps
• Maximum Resolution: 1920x1200@60Hz
• Video EDID:
• 1024x768@75Hz
• 1152x864@75Hz
• 1280x720@60Hz
• 1280x768@60Hz
• 1280x960@60Hz
• 1280x1024@60Hz/75Hz
• 1366x768@60Hz
• 1440x900@60Hz
• 1600x900@60Hz
• 1600x1200@60Hz
• 1680x1050@60Hz
• 1920x1080@60Hz
• 1920x1200@60Hz
• Input: VGA (Female)
• Output: VGA (Male)
• Power: Powered by source device, 3.5/1.35mm (Optional)
• Dimensions (approx.) WxDxH: 33x59x14mm (1.3x2.32x0.55in)
• Housing Material: Metal
• Net Weight: 0.027kg (0.06lb)
• Operating Temperature: 0°C - 50°C (32°F - 122°F)
• Storage Temperature: -20°C - 80°C (-4°F - 176°F)
• Humidity: 0 - 90% RH (non-condensing)
• Power Requirements: 5VDC 500mA (Optional)
• Colour: Black
• Packaging Type: Polybag
• Packaging Dimensions: 133x144mm (5.24x5.67in)
• Gross Weight: 0.042kg (0.09lb)
• Warranty (Years): 2
• Certificated: CE, FCC, RoHS, REACH & California Proposition 65

Package Contents:

• VGA EDID Emulator
• Lindy Manual

EDID - Extended Display Identification Data.
It is a way for a video source to discover the capabilities of the sink (display device) it is connected to. EDID information resides in the sink and is made available through the connection to a source device via HDMI, DP, DVI etc. When a sink is connected to a source it receives power for its EDID circuit from the source.
