Kramer WP-211T/EU-80/86(W) Wall–Plate Switcher/Transmitter
WP-211T is a high-performance
PoE-powered wall-plate automatic switcher of 4K HDMI video signals, transmitted over long-reach HDBaseT extension link. Offering priority and last-connected switching options, it automatically switches according to the selected switching scheme based on active video signal detection.
Features
- 2x1 Plug and Play Wall–mounted Switching
- Up to 4K@60Hz (4:2:0) Resolution
- Up to 70m (230ft) Reach
Automatic input selectionPlug & play auto switching based on last connected input or manual selection.
High performance switcher transmitterProfessional HDBaseT switcher transmitter for providing long - reach signals over
twisted pair copper infrastructures. This switcher transmitter is a standard transmitter that can be connected to any market - available HDBaseT - compliant extension product.
HDMI signal switchingHDMI 2.0 and HDCP 2.2 compliant, it supports deep color, x.v.Color, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS - HD, 2K, 4K, and 3D.
Multi - channel audio switchingUp to 32 channels of digital stereo uncompressed signals for supporting studio - grade surround sound.
I - EDIDPro Kramer intelligent EDID processingIntelligent EDID handling, processing, locking and pass - through algorithm ensures Plug and Play operation for HDMI source and display systems.
Reliable PoE (Power over Ethernet) PoweringAuto - senses the extension line PoE status, it accepts power from a remote PoE provider such as a PoE matrix, with optional mains powering from connected power adapter.
Easy installationCompactly fits into standard US, EU and UK 1 - gang in - wall box size, supporting decorative integration with room deployed user interfaces such as electrical switches. Wall - plate installation is fast and cost - effective via a single twisted pair cable, providing both video signal and power (PoE) connections.
WP-211T is a high-performance PoE-powered wall-plate automatic switcher of 4K HDMI video signals, transmitted over long-reach HDBaseT extension link. Offering priority and last-connected switching options, it automatically switches according to the selected switching scheme based on active video signal detection.
Features
- 2x1 Plug and Play Wall–mounted Switching
- Up to 4K@60Hz (4:2:0) Resolution
- Up to 70m (230ft) Reach
Automatic input selectionPlug & play auto switching based on last connected input or manual selection.
High performance switcher transmitterProfessional HDBaseT switcher transmitter for providing long - reach signals over twisted pair copper infrastructures. This switcher transmitter is a standard transmitter that can be connected to any market - available HDBaseT - compliant extension product.
HDMI signal switchingHDMI 2.0 and HDCP 2.2 compliant, it supports deep color, x.v.Color, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS - HD, 2K, 4K, and 3D.
Multi - channel audio switchingUp to 32 channels of digital stereo uncompressed signals for supporting studio - grade surround sound.
I - EDIDPro Kramer intelligent EDID processingIntelligent EDID handling, processing, locking and pass - through algorithm ensures Plug and Play operation for HDMI source and display systems.
Reliable PoE (Power over Ethernet) PoweringAuto - senses the extension line PoE status, it accepts power from a remote PoE provider such as a PoE matrix, with optional mains powering from connected power adapter.
Easy installationCompactly fits into standard US, EU and UK 1 - gang in - wall box size, supporting decorative integration with room deployed user interfaces such as electrical switches. Wall - plate installation is fast and cost - effective via a single twisted pair cable, providing both video signal and power (PoE) connections.
