| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | KINKSM64R52BD4-64MD |
| Manufacturer No: | KSM64R52BD4-64MD |
| Delivery: | Out Of Stock |
 |
The Kingston KSM64R52BD4-64MD is a 64GB DDR5 ECC Registered DIMM with a 6400MT/s data transfer rate and CL52 latency. The 288-pin module uses a 2Rx4 dual-rank configuration with 16Gbit Micron D-Die DRAM and operates at 1.1V. It provides x80 ECC with two independent I/O subchannels and is intended for compatible server platforms requiring high-capacity DDR5 registered memory.
The 64GB capacity provides substantial memory space for compatible server systems using DDR5 ECC Registered DIMMs. The dual-rank 2Rx4 configuration is built from forty 4G x 4-bit FBGA components.
The module operates at a DDR5-6400 data transfer rate with CL52 latency. Its SPD is programmed to the JEDEC standard DDR5-6400 timing of 52-52-52 at 1.1V for compatible memory controllers.
The Registered DIMM format provides buffered memory operation for compatible server platforms. On-die ECC provides error checking within the DDR5 memory components, while the x80 ECC configuration provides an additional ECC data path with two independent I/O subchannels.
The module uses a 2Rx4 dual-rank configuration with 16Gbit DRAM density. The 288-pin DIMM features gold contact fingers and a PCB height of 31.25mm for installation in compatible DDR5 memory slots.
The memory module uses Micron D-Die DRAM with a 16Gbit density. This component configuration provides the memory organisation required for the 64GB registered ECC DIMM.
The Kingston KSM64R52BD4-64MD is a 64GB DDR5 ECC Registered DIMM with a 6400MT/s data transfer rate and CL52 latency. The 288-pin module uses a 2Rx4 dual-rank configuration with 16Gbit Micron D-Die DRAM and operates at 1.1V. It provides x80 ECC with two independent I/O subchannels and is intended for compatible server platforms requiring high-capacity DDR5 registered memory.
The 64GB capacity provides substantial memory space for compatible server systems using DDR5 ECC Registered DIMMs. The dual-rank 2Rx4 configuration is built from forty 4G x 4-bit FBGA components.
The module operates at a DDR5-6400 data transfer rate with CL52 latency. Its SPD is programmed to the JEDEC standard DDR5-6400 timing of 52-52-52 at 1.1V for compatible memory controllers.
The Registered DIMM format provides buffered memory operation for compatible server platforms. On-die ECC provides error checking within the DDR5 memory components, while the x80 ECC configuration provides an additional ECC data path with two independent I/O subchannels.
The module uses a 2Rx4 dual-rank configuration with 16Gbit DRAM density. The 288-pin DIMM features gold contact fingers and a PCB height of 31.25mm for installation in compatible DDR5 memory slots.
The memory module uses Micron D-Die DRAM with a 16Gbit density. This component configuration provides the memory organisation required for the 64GB registered ECC DIMM.
Product data is provided by Icecat, we do not warrant the accuracy of the material above.
