| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | JNSRX4600-4PST-RMK |
| Manufacturer No: | SRX4600-4PST-RMK |
| Delivery: | In Stock: 5-7 Days |
 |
Rack mount kit
4-post adjustable for SRX4600
You can mount an SRX4600 services gateway on four posts of a 19-in. rack or cabinet by using the four-post rack-mount kit.
To mount the services gateway on four posts of a rack:
1. Remove the services gateway from the shipping carton
2. Attach the front-mounting brackets (either the flush or the 2-in.-recess brackets) to the side mounting rails by using 6 Phillips 4-40 flat-head mounting screws.
3. Place the services gateway on a flat, stable surface.
4. Align the side mounting rails along the side panels of the services gateway chassis. Align the two holes in the rear of the side mounting rails with the two holes on the rear of the side panel.
5. Insert the Phillips 4x6-mm flat-head mounting screws into the two aligned holes and tighten the screws. Ensure that the two holes in the rear of the side mounting rails are aligned with the remaining two holes in the side panel.
6. Insert the Phillips 4x6-mm flat-head mounting screws into the remaining two holes in the side mounting-rails and tighten the screws.
7. Have one person grasp both sides of the services gateway, lift the services gateway, and position it in the rack, aligning the side mounting rail holes with the threaded holes in the front post of the rack. Align the bottom hole in both the front-mounting brackets with a hole in each rack rail, making sure that the chassis is level.
8. Have a second person secure the front of the services gateway to the rack by using the appropriate screws for your rack.
9. Slide the rear mounting blades into the side mounting rails.
10. Attach the rear mounting blades to the rear post by using the appropriate screws for your rack. Tighten the screws.
11. Ensure that the services gateway chassis is level by verifying that all the screws on the front of the rack are aligned with the screws at the back of the rack.
