Excel Vert C13, C19 Socket Passive 16A IEC 60309 Plug PDU

Excel range of power distribution units are designed for installation and use within 19" networking cabinets and enclosures. Each unit comprises a high quality aluminium extruded housing into which are loaded up to 24 sockets in a combination of C13 and C19.

The range of units are higher density vertical mounted with each unit fitted with a 16A master air circuit breaker and LED indicator to confirm power to the unit.

Features

• 3 metre PVC input lead is terminated with a 16 Amp rated IEC 60309 2P+E plug
• CE compliant, RoHS complaint
• 16A master air circuit breaker
• External earth facility

Specifications

• Mounting size: 913mm (16-Way) | 1079mm (20-Way) | 1245mm (24-Way)
• Mounting direction: Vertical
• Electrical connection: Connecting cord with plug
• Type of electric plug connection: 16 Amp - EN6039 Style (BS4343)
• Cable length: 3 m
• Number of c13 socket outlets: 12 (16-Way) | 16 (20-Way) | 20 (24-Way)
• Number of c19 socket outlets: 4 (All Models)
• Number of rack units (ru): 1
• Dimensions (W x H x D): (See Mounting Size) x 55 mm x 62 mm
• Supply voltage: 230 V
• Surge protected: Yes
• With led indication: Yes
• With fuse: Yes
• With mounting bracket: Yes
