Browse Categories
In Stock: Next Day
£2.11
£2.53 Inc VAT.
Earn 1 Data Point when purchasing this product. More Info
Qty:

Excel Cat5e Chrome Screened Butterfly Keystone Jack

Toolless

by Excel
See more product details
Part No:MODKTS
Manufacturer No:100-906
Delivery: In Stock: Next Day
Buy this Product
and save
10%
off
(Discount will be applied during checkout)
Similar & Related Items (See All)
Qty:
Click to change options
Colour:
Apply
£2.93 Ex VAT
Qty:
Click to change options
Colour:
Apply
£1.94 Ex VAT
More Related Items
Click to change options
Ports:
Apply
£27.27 Ex VAT
Qty:
Click to change options
Colour:
Apply
£0.75 Ex VAT
Qty:
Email product to a friend
X
  • Scroll to top
    Excel Cat5e Chrome Screened Butterfly Keystone Jack
    Toolless

    The Excel Category 5e Screened Twisted Pair (F/FTP) Keystone Jack, is a toolless termination RJ45 socket suitable for mounting in range of housings from patch panels, faceplates and shutters to sub floor boxes, and work areas distribution enclosures. The socket itself is housed in a high quality zinc die cast housing, which opens at the rear in a butterfly manner to reveal the IDC termination points. Once the conductors of the cable to be terminated are fed into a management cap the process is completed by snapping the butterfly wings together with minimal, but firm pressure. A choice of Patch Panel frames with either 16 or 24 port density in both black and chrome are available.

    Features:

    • Category 5e Compliant
    • High quality die cast housing
    • Toolless termination design
    • Suitable for patch panel and faceplate mounting
    • Suitable for installation in 37mm deep back box with bevelled faceplate
    • Lifetime Product Warranty
    • 25 year system warranty available
    • Independently verified
    • 360° Shielding protects against alien crosstalk

    Keystone Jack Fits The Following Modular Panels:

    • PANK24 - Excel 24 port 1U Unloaded Black Keystone Frame
    • PANK16-6A - Excel 16 port 1U Unloaded Chrome Keystone Frame
    • PANK24-6A - Excel 24 port 1U Unloaded Chrome Keystone Frame
    • PANK24V - Excel 24 port Keystone V Patch Panel Frame
