Excel 12 Way Vertical C13 Socket C20 Plug Switched PDU

The Excel range of power distribution units are designed for installation and use within 19" networking cabinets and enclosures. Each unit comprises a high quality aluminium extruded housing into which are loaded up to 12 sockets. In this particular range each socket is IEC C13 style, the 3 metre input lead is terminated with a C20 3 pin plug.

The range of available units includes 19" vertical mounted options, each unit contains a fully shrouded switch to control input power, and a LED indicator to confirm power to the unit.

Features

• IEC 60320 C13 style sockets
• High quality, light weight aluminium housing
• LED indicated unit power
• Choose from vertical and horizontal options
• 250 volt AC, 50/60 Hz rating
• CE compliant, ROHS complaint

Specifications

• Mounting size: 719 mm
• Mounting direction: Vertical
• Electrical connection: Connecting cord with plug
• Type of electric plug connection: C20
• Cable length: 3 m
• Number of c13 socket outlets: 12-Way
• Number of rack units (ru): 2
• Dimensions (W x H x D): (See Mounting Size) x 44.4 x 62 mm
• Supply voltage: 250 V
• Surge protected: No
• Switchable: Yes
• With led indication: Yes
• With fuse: No
• With mounting bracket: Yes
