Cisco Meraki MX95-HW Router/Security Appliance

The Cisco Meraki MX95-HW is a 1U cloud-managed security and SD-WAN appliance built for medium-sized branch sites and distributed deployments of up to 500 users. It combines next-generation firewall, IDS/IPS, content filtering and Advanced Malware Protection into a single rack-mounted unit, all configured and monitored through the Meraki dashboard. A separate Meraki licence is required for activation and ongoing management.

Key Features

• 2 Gbps stateful firewall throughput and 800 Mbps site-to-site VPN throughput
• 4x dedicated WAN uplinks: 2x 10 GbE SFP+ and 2x 2.5 GbE RJ45 (one with PoE+)
• 6x LAN ports: 4x 1 GbE RJ45 and 2x 10 GbE SFP+
• USB 3.0 port for 4G/5G cellular failover
• Cisco Talos-backed AMP, IDS/IPS and Layer 7 content filtering
• Meraki Auto VPN, Cisco AnyConnect and standard IPsec support

Benefits

• Zero-touch provisioning removes the need for an on-site engineer at deployment
• Replaces separate firewall, SD-WAN, VPN and content filtering boxes with one unit
• Cloud-managed via the Meraki dashboard from anywhere with a browse
• 10 GbE uplinks and LAN ports leave clear headroom for fibre WAN circuits

Product Comparison

• Cisco Meraki MX85 - the step-down model for smaller branches with lower firewall throughput; same feature set
• Cisco Meraki MX105 - the step-up model with 5 Gbps firewall throughput and dual redundant power supplies, suited to larger branches where uptime is critical
• Fortinet FortiGate 90G - a similar mid-range NGFW from a different vendor, typically chosen where IT teams prefer locally managed FortiOS over a cloud-managed dashboard

Sizing and Capacity

1U rack-mountable chassis at 484.6mm wide, 285.2mm deep and 44mm high, weighing 3.17kg. Rated for up to 500 concurrent users with 2 Gbps firewall throughput and 800 Mbps VPN throughput. Mounts in any standard 19-inch rack. A single non-redundat power supply is fitted - step up to the MX105 if redundant power is required.

Who It's For
Mid-size businesses, multi-site branch deployments, retail, healthcare and finance environments needing PCI-compliant edge security, and IT teams standardising on the Cisco Meraki ecosystem for unified network and security management.

FAQs

• Is a Meraki licence included with the hardware? No. A Meraki licence (Enterprise, Advanced Security or Secure SD-WAN Plus) must be purchased separately to activate and manage the appliance.
• Can it act as a primary firewall? Yes. The MX95 is a full next-generation firewall with Layer 7 inspection, IDS/IPS and AMP, not a routing-only appliance.
• Does it support remote worker VPN? Yes. Meraki Auto VPN, Cisco AnyConnect and standard IPsec are all supported for site-to-site and client VPN.
• What's the difference between the MX95 and MX105? The MX105 offers higher throughput (5 Gbps firewall) and dual redundant power supplies. The feature set is otherwise identical.
• Can the WAN PoE+ port power a 4G/5G modem? Yes, one of the 2.5 GbE WAN ports delivers PoE+ to power a compatible cellular gateway.

Specifications

As per Cisco's UK policy we are unable to ship any Cisco products to any address other than a company registered address as shown on Companies House.
