The Cisco Meraki MX95-HW is a 1U cloud-managed security and SD-WAN appliance built for medium-sized branch sites and distributed deployments of up to 500 users. It combines next-generation firewall, IDS/IPS, content filtering and Advanced Malware Protection into a single rack-mounted unit, all configured and monitored through the Meraki dashboard. A separate Meraki licence is required for activation and ongoing management.
4x dedicated WAN uplinks: 2x 10 GbE SFP+ and 2x 2.5 GbE RJ45 (one with PoE+)
6x LAN ports: 4x 1 GbE RJ45 and 2x 10 GbE SFP+
USB 3.0 port for 4G/5G cellular failover
Cisco Talos-backed AMP, IDS/IPS and Layer 7 content filtering
Meraki Auto VPN, Cisco AnyConnect and standard IPsec support
Benefits
Zero-touch provisioning removes the need for an on-site engineer at deployment
Replaces separate firewall, SD-WAN, VPN and content filtering boxes with one unit
Cloud-managed via the Meraki dashboard from anywhere with a browse
10 GbE uplinks and LAN ports leave clear headroom for fibre WAN circuits
Product Comparison
Cisco Meraki MX85 - the step-down model for smaller branches with lower firewall throughput; same feature set
Cisco Meraki MX105 - the step-up model with 5 Gbps firewall throughput and dual redundant power supplies, suited to larger branches where uptime is critical
Fortinet FortiGate 90G - a similar mid-range NGFW from a different vendor, typically chosen where IT teams prefer locally managed FortiOS over a cloud-managed dashboard
Sizing and Capacity
1U rack-mountable chassis at 484.6mm wide, 285.2mm deep and 44mm high, weighing 3.17kg. Rated for up to 500 concurrent users with 2 Gbps firewall throughput and 800 Mbps VPN throughput. Mounts in any standard 19-inch rack. A single non-redundat power supply is fitted - step up to the MX105 if redundant power is required.
Who It's For Mid-size businesses, multi-site branch deployments, retail, healthcare and finance environments needing PCI-compliant edge security, and IT teams standardising on the Cisco Meraki ecosystem for unified network and security management.
FAQs
Is a Meraki licence included with the hardware? No. A Meraki licence (Enterprise, Advanced Security or Secure SD-WAN Plus) must be purchased separately to activate and manage the appliance.
Can it act as a primary firewall? Yes. The MX95 is a full next-generation firewall with Layer 7 inspection, IDS/IPS and AMP, not a routing-only appliance.
Does it support remote worker VPN? Yes. Meraki Auto VPN, Cisco AnyConnect and standard IPsec are all supported for site-to-site and client VPN.
What's the difference between the MX95 and MX105? The MX105 offers higher throughput (5 Gbps firewall) and dual redundant power supplies. The feature set is otherwise identical.
Can the WAN PoE+ port power a 4G/5G modem? Yes, one of the 2.5 GbE WAN ports delivers PoE+ to power a compatible cellular gateway.
19.08" x 11.23" x 1.73" (484.6 mm x 285.2 mm x 44 mm)
Weight
6.99 lbs (3.17 kg)
Power supply
Internal 100-127VAC, 200-240VAC (50/60Hz)
Power load (idle/max)
42W/109W
Operating temperature
32°F to 104°F (0°C to 40°C)
Humidity
5% to 95%
As per Cisco's UK policy we are unable to ship any Cisco products to any address other than a company registered address as shown on Companies House.
The Cisco Meraki MX95-HW is a 1U cloud-managed security and SD-WAN appliance built for medium-sized branch sites and distributed deployments of up to 500 users. It combines next-generation firewall, IDS/IPS, content filtering and Advanced Malware Protection into a single rack-mounted unit, all configured and monitored through the Meraki dashboard. A separate Meraki licence is required for activation and ongoing management.
4x dedicated WAN uplinks: 2x 10 GbE SFP+ and 2x 2.5 GbE RJ45 (one with PoE+)
6x LAN ports: 4x 1 GbE RJ45 and 2x 10 GbE SFP+
USB 3.0 port for 4G/5G cellular failover
Cisco Talos-backed AMP, IDS/IPS and Layer 7 content filtering
Meraki Auto VPN, Cisco AnyConnect and standard IPsec support
Benefits
Zero-touch provisioning removes the need for an on-site engineer at deployment
Replaces separate firewall, SD-WAN, VPN and content filtering boxes with one unit
Cloud-managed via the Meraki dashboard from anywhere with a browse
10 GbE uplinks and LAN ports leave clear headroom for fibre WAN circuits
Product Comparison
Cisco Meraki MX85 - the step-down model for smaller branches with lower firewall throughput; same feature set
Cisco Meraki MX105 - the step-up model with 5 Gbps firewall throughput and dual redundant power supplies, suited to larger branches where uptime is critical
Fortinet FortiGate 90G - a similar mid-range NGFW from a different vendor, typically chosen where IT teams prefer locally managed FortiOS over a cloud-managed dashboard
Sizing and Capacity
1U rack-mountable chassis at 484.6mm wide, 285.2mm deep and 44mm high, weighing 3.17kg. Rated for up to 500 concurrent users with 2 Gbps firewall throughput and 800 Mbps VPN throughput. Mounts in any standard 19-inch rack. A single non-redundat power supply is fitted - step up to the MX105 if redundant power is required.
Who It's For Mid-size businesses, multi-site branch deployments, retail, healthcare and finance environments needing PCI-compliant edge security, and IT teams standardising on the Cisco Meraki ecosystem for unified network and security management.
FAQs
Is a Meraki licence included with the hardware? No. A Meraki licence (Enterprise, Advanced Security or Secure SD-WAN Plus) must be purchased separately to activate and manage the appliance.
Can it act as a primary firewall? Yes. The MX95 is a full next-generation firewall with Layer 7 inspection, IDS/IPS and AMP, not a routing-only appliance.
Does it support remote worker VPN? Yes. Meraki Auto VPN, Cisco AnyConnect and standard IPsec are all supported for site-to-site and client VPN.
What's the difference between the MX95 and MX105? The MX105 offers higher throughput (5 Gbps firewall) and dual redundant power supplies. The feature set is otherwise identical.
Can the WAN PoE+ port power a 4G/5G modem? Yes, one of the 2.5 GbE WAN ports delivers PoE+ to power a compatible cellular gateway.
