Cat5e RJ45 Neutrik etherCON Shielded Patch Lead

These cables are manufactured using high quality shielded cat5e cable in yellow, with high quality cat5e RJ45 connectors with the added Neutrik Ethercon Connectors.

The Neutrik Ethercon is an RJ45 cable connector carrier for preassembled RJ45 plugs consists of shell, fixing disk, chuck, bushing and boot. Packed with two cable protection elements for cable diameter either up to 5 mm or 8 mm. Cable connector carrier does not include a RJ45 plug.

The etherCON cable connector carrier upgrades a conventional RJ45 connector to an extremely robust lockable solution.

Attention! Does not intermate with Neutrik CAT6 chassis connectors NE8FDY-C6 and NE8FDY-C6-B.

Features & Benefits

• The RJ45 system for harsh and demanding environment
• Cable connector carrier accepts the most common RJ45 plugs (see list at downloads)
• Rugged diecast shell and unique chuck type strain relief
• Protects Ethernet connections in a variety of commercial type applications and is designed to prevent breakage of the fragile components of standard RJ 45 connectors

Ethercon Connector Tech Specs

Mechanical

• Cable O.D. max. 8mm 0.315'
• Insertion force ≤ 20N
• Withdrawal force ≤ 20N
• Lifetime > 1000 mating cycles

Material

• Boot - Polyamide (PA 6)
• Shell-Zinc Diecast (ZnAl4Cu1)
• Shell Plating - Nickel
• Strain Relief - Polyacetal (POM)

Enviromental

• Temperature Range: -30ºC to +80ºC
