| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | FE02208-001 |
| Manufacturer No: | 02208-001 |
| Delivery: | In Stock: 1-2 Days |
 |
AXIS 30 W Midspan AC/DC
When mains power is not an option, 30 W
• 24 V AC and 10-28 V DC input
• IEEE 802.3af and 802.3at output
• Compatible with Axis PoE devices
• Flexible installation
• Plug-and-play
AXIS 30 W Midspan AC/DC is ideal for installations where mains power is not an option. With a power input of either 10-28 V DC or 24 V AC, it can deliver up to IEEE 802.3at (30 W) to your network device. AXIS 30 W Midspan AC/DC is plug-and-play and compatible with all Axis PoE devices which require up to 30 W power.
24 V AC can be needed in harsh environments where new cabling or installations are not possible and you need to retrofit box, dome or PTZ cameras.
10-28 V DC can be used where battery back-up is needed or for solar-powered installations. Or when the network device is built in another equipment and is powered directly from it, for example, in an ATM.
| Features | |
| Wall mountable | Yes |
| Product colour | Black |
| LED indicators | Yes |
| Technical details | |
| Input voltage | 10-18 V |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Doesn't contain | PVC |
| Power | |
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage temperature (T-T) | -40 - 75 °C |
AXIS 30 W Midspan AC/DC
When mains power is not an option, 30 W
• 24 V AC and 10-28 V DC input
• IEEE 802.3af and 802.3at output
• Compatible with Axis PoE devices
• Flexible installation
• Plug-and-play
AXIS 30 W Midspan AC/DC is ideal for installations where mains power is not an option. With a power input of either 10-28 V DC or 24 V AC, it can deliver up to IEEE 802.3at (30 W) to your network device. AXIS 30 W Midspan AC/DC is plug-and-play and compatible with all Axis PoE devices which require up to 30 W power.
24 V AC can be needed in harsh environments where new cabling or installations are not possible and you need to retrofit box, dome or PTZ cameras.
10-28 V DC can be used where battery back-up is needed or for solar-powered installations. Or when the network device is built in another equipment and is powered directly from it, for example, in an ATM.
| Features | |
| Wall mountable | Yes |
| Product colour | Black |
| LED indicators | Yes |
| Technical details | |
| Input voltage | 10-18 V |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Doesn't contain | PVC |
| Power | |
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage temperature (T-T) | -40 - 75 °C |
Product data is provided by Icecat, we do not warrant the accuracy of the material above.
