Aten VC840 HDMI to 3G/HD/SD-SDI Converter

Overview

The VC840 HDMI to 3G/HD/SD SDI Converter provides a professional way to exchange high definition signals in real time. The SDI and HDMI signal conversion is 100% digital and guarantees no loss of quality for both the audio and video transmission. The VC840 provides 2 low jitter SDI outputs for dual display. The VC840 is the most dependable way to convert signals with confidence when monitoring in any post or broadcast application.

Package Contents

• 1x VC840 HDMI to 3G/HD/SD-SDI Converter
• 1x Power Adapter
• 1x User Instructions

Features

• Converts an HDMI input signal to 3G/HD/SD-SDI formats in real time while avoiding transformation loss for both audio and video signals
• Supports additional analog stereo audio and coaxial digital audio
• HDMI (Deep Color)
• LED indication of power and signal status
• Supports an SDI distance of up to 90M (3G-SDI), 150M (HDSDI) or 300M (SD-SDI) of RG6
• Supported SDI formats:
• SD-SDI (SMPTE 259M, up to 270Mbps)
• HD-SDI (SMPTE 292M, 296M, up to 1.485Gbps)
• 3G-SDI (SMPTE 424M, 425M level A, up to 2.97Gbps)
• Video Support:
• [email protected], 625i@50
• 720p@50/59.94/60
• 1080i@50/59.94/60
• [email protected]/24/25/29.97/30/50/59.94/60
• Supports 8 audio channels @ 48kHz rate
• Offers 2 low-jitter SDI outputs for dual display
• Features automatic detection of 3G/HD/SD-SDI signals
• Reclocking SDI signals for cascading and thus longer transmission
• Locking power connector for secure communications
• Selectable EDID settings and EDID learning mode
