Extend your computer's keyboard, video, and mouse signals over long distances with Aten's extensive range of USB KVM extenders. Comms Express offers Aten's complete selection of KVM extenders to enable remote access and control between computers and consoles up to 150m apart. Find the perfect KVM extender for your needs from the leading supplier of data cabling and connectivity solutions.
Overview
The CE600 is a DVI and USB based KVM Extender with RS-232 serial functionality
It allows access to a computer system from a remote console (USB keyboard, monitor, and mouse)
Because it allows access to a computer system from a remote console, the CE600 is perfect for use in any type of installation where you need to place the console where it is conveniently accessible, but you want the system equipment to reside in a safe location – away from the dust and dirt of the factory floor, or the harsh environmental infl uence of a construction site, for example
This allows users to deploy system equipment over large distances.
Product Features
Local and Remote Units connect at distances up to 60 m using Cat 5e cable
Features ATEN technology that allows A/V transmission over one cat 5e cable
Superior video quality of up to 1920 x 1200 @ 60 Hz at 30 m; 1024 x 768 @ 60 Hz at 60 m – get an excellent, crisp image on your screen over long distance transmissions
Manual compensation control to adjust signal strength in order to compensate for distance
Overview
The CE602 is a DVI Dual Link and USB based KVM Extender with RS-232 serial functionality
It allows access to a computer system from a remote console (USB keyboard, monitor, and mouse)
Because it allows access to a computer system from a remote console, the CE602 is perfect for use in any type of installation where you need to place the console where it is conveniently accessible, but you want the system equipment to reside in a safe location – away from the dust and dirt of the factory floor, or the harsh environmental influence of a construction site, for example
This allows users to deploy system equipment over large distances.
Product Features
Local and Remote Units connect at distances up to 60 m using Cat 5e cable
Supports DVI-D interface and allows transmission of DVI duallink signals
Superior video quality of up to 2560 x 1600 @ 60 Hz (DVI Dual Link) at 40 m; 1024 x 768 @ 60 Hz at 60 m – get an excellent, crisp image on your screen over long distance transmissions
Manual compensation control to adjust signal strength in order to compensate for distance
Overview
The CE770 is a USB based KVM Extender with Deskew function
The automatic signal compensation and RS-232 serial functionality allow access to a computer system from a remote USB console.
The CE770 supports RGB delay tuner to manually synchronize the RGB signals
This allows users to deploy system equipment over large distances
The CE770's line synchronizing function corrects color phase and timing errors that occur over long distance transmissions
It also enables you to manually tune the R/G/B signal settings
Product Features
Local and Remote Units connect at distances up to 300 m using Cat 5e cable
Dual console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles
High resolution video - up to 1920 x 1200@60Hz (150 m); 1280 x 1024@60Hz (300 m)
Deskew Function - automatically synchronizes the time delay of RGB signals to compensate for distance
Overview
ATEN CE774 Dual View KVM Extenders allows access to a computer system from a remote Dual View console up to 150 m away
The dual view function provides support for two displays, allowing the video output to seamlessly display on two monitors
Its advanced PC Wake - Up feature that allows you simply uses a pushbutton from the remote dual view console to wake a PC at the local site via RS-232, no need to go to the local site to wake up the PC
It eliminates the need for traveling back and forth between the local computer and remote console, effi cient and flexible
Use the improved built-in front panel tuners to easily adjust the picture quality.
Product Features
Dual View Support - connect two screens to transmit two video output signals to a remote site up to 150 m away using inexpensive Cat 5e/6 cables
Dual Console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles
Superior video quality - 1920x1200@60Hz(30 m), 1600x1200@60Hz(150 m)
Gain/Compensation Control - adjusts signal strength in order to compensate for distance
Overview
ATEN CE775 Dual View KVM Extenders with Deskew function allows access to a computer system from a remote Dual View console up to 300 m away
The dual view function provides support for two displays, allowing the video output to seamlessly display on two monitors
Its advanced PC Wake - Up feature that allows you simply uses a pushbutton from the remote dual view console to wake a PC at the local site via RS-232, no need to go to the local site to wake up the PC
It eliminates the need for traveling back and forth between the local computer and remote console, effi cient and flexible.
Use the improved built-in front panel tuners to easily adjust the picture quality
In addition, you can automatically synchronize the time delay of RGB signals in order to compensate for distance, easy and fast than ever.
Product Features
Dual View Support - connect two screens to transmit two video output signals to a remote site up to 300 m away using inexpensive Cat 5e/6 cables
Dual Console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles
Superior video quality – 1920x1200@60Hz(150 m), 1280x1024@60Hz(300 m)
Deskew Function – automatically synchronizes the time delay of RGB signals to compensate for distance
Product Overview
The CE100 USB KVM Extender with superior video quality and built-in ESD protection allows access to a computer system from a remote USB console (USB keyboard, USB mouse, and monitor).
The CE100 improves on previous designs by: 1) incorporating a compensation adjustment function at the Remote unit for greater video quality; and 2) using inexpensive Cat 5e cable, instead of bulky, expensive, standard cables, to provide a neater, more convenient, more reliable data transfer connection.
Product Features
Extends local PC VGA/keyboard/Mouse to Remote side
Superior video quality – up to 1920 x 1200
Uses Cat 5e cable to connect the local and remote units
Allow access to a computer from the remote console up to 100 m distance
Product Diagram
The CE700A is a USB KVM Extender with superior video quality and built-in ESD and surge protection that allows access to a computer system up to 150 meters away from a remote USB console (USB keyboard, monitor, and USB mouse).
The CE700A improves on previous designs by:
Incorporating 8KV/15KV ESD protection and 2KV surge protection
Providing superior video quality - up to 1920 x 1200 resolution
Using inexpensive Cat 5e cable, instead of bulkier, more expensive, standard cables, for a much neater, more convenient, more reliable data transfer connection
It is able to sense the distance to the system and automatically adjusts the gain accordingly
It features a custom ASIC to ensure the utmost in reliability and compatibility.
KVM Switch Features
Cat 5e cable connects the Local and Remote Units - up to 150m apart
Dual console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles
Built-in ASIC for greater reliability and compatibility
Auto Signal Compensation (ASC)
USB Keyboard and USB Mouse Ports
USB overcurrent detection and prevention
Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes.
Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection
Automatic gain control - adjusts signal strength to compensate for distance
High resolution video - up to 1920 x 1200@60Hz (30m ); 1600 x 1200@60Hz (100m); 1280 x 1024@60Hz (150m)
Supports Wide Screen formats
Supports VGA, SVGA, SXGA, UXGA, WUXGA and multi sync monitors; local monitor supports DDC; DDC2; DDC2B
Rack mountable
Easy to install - no software required - connecting cables to the devices is all it takes
Multiplatform support - Windows, Linux
Package Contents
1x CE700AL USB KVM Extender (Local Unit)
1x CE700AR USB KVM Extender (Remote Unit)
1x Custom KVM Cable (VGA, USB; 1.8m/6ft)
2x Power Adapters
1x Mounting Kit
1x User Instructions
The CE600 is a DVI and USB based KVM Extender with RS-232 serial functionality. It allows access to a computer system from a remote console (USB keyboard, monitor, and mouse).
Because it allows access to a computer system from a remote console, the CE600 is perfect for use in any type of installation where you need to place the console where it is conveniently accessible, but you want the system equipment to reside in a safe location - away from the dust and dirt of the factory floor, or the harsh environmental infl uence of a construction site, for example. This allows users to deploy system equipment over large distances.
The CE600 users one Cat 5e cable (DVI Single Link) to support up to 1920 x 1200 video resolution
KVM Switch Features
Local and Remote Units connect at distances up to 60 m using Cat 5e cable
Allows access to a computer or KVM installation from a remote console (up to 60 m)
Features ATEN technology that allows A/V transmission over one cat 5e cable
The 2nd Cat 5e cable is used for HDCP, RS-232, and microphone signals
Manual compensation control to adjust signal strength in order to compensate for distance
Audio Enabled - supports stereo speakers and microphone
Auto Signal Compensation (ASC) and storage of settings
RS-232 serial ports - connect to a serial terminal, or serial devices such as touchscreens and barcode scanners (Baud Rate up to 115200 bps)
Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
Supports Wide Screen formats
Superior video quality of up to 1920 x 1200 @ 60 Hz at 30 m; 1024 x 768 @ 60 Hz at 60 m - get an excellent, crisp image on your screen over long distance transmissions
Hot pluggable
Rack mountable
Easy to install - no software required - connecting cables to the devices is all it takes
Firmware upgrade
Package Contents
1x CE600L DVI KVM Extender (Local Unit)
1x CE600R DVI KVM Extender (Remote Unit)
1x Custom KVM Cable (DVI-D Single Link, USB, Audio; 1.8m/6ft)
2x Power Adapters
1x Mounting Kit
1x User Instructions
The CE770 is a USB based KVM Extender with Deskew function. The automatic signal compensation and RS-232 serial functionality allow access to a computer system from a remote USB console.
The CE770 supports RGB delay tuner to manually synchronize the RGB signals. This allows users to deploy system equipment over large distances. The CE770's line synchronizing function corrects color phase and timing errors that occur over long distance transmissions. It also enables you to manually tune the R/G/B signal settings.
KVM Switch Features
Local and Remote Units connect at distances up to 300 m using Cat 5e cable
Dual console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles
Deskew Function - automatically synchronizes the time delay of RGB signals to compensate for distance
Built-in ASIC for greater reliability and compatibility
Auto Signal Compensation (ASC)
RS-232 serial ports - allow you to connect to a serial terminal, or serial devices such as touchscreens and barcode scanners
Sun/Mac keyboard support and emulation
Audio Enabled - supports stereo speakers and microphone
USB overcurrent detection and prevention
Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes, with the press of a single button
Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection
High resolution video - up to 1920 x 1200@60Hz (150 m); 1280 x 1024@60Hz (300 m)
Superior Audio - no loss in audio quality at 300 m
Supports Wide Screen formats
Supports VGA, SVGA, SXGA (1280 x 1024), UXGA (1600 x 1200), WUXGA (1920 x 1200) and multisync monitors; local monitor supports DDC; DDC2; DDC2B
Hot pluggable
Rack mountable
Easy to install - no software required - connecting cables to the devices is all it takes
Package Contents
1x CE770L USB KVM Extender (Local Unit)
1x CE770RQ USB KVM Extender (Remote Unit)
1x Custom KVM Cable (VGA, USB, Audio; 1.8m/6ft)
2x Power Adapters
1x Mounting Kit
1x User Instructions
ATEN CE775 Dual View KVM Extenders with Deskew function allows access to a computer system from a remote Dual View console up to 300 m away. The dual view function provides support for two displays, allowing the video output to seamlessly display on two monitors.
Its advanced PC Wake - Up feature that allows you simply uses a pushbutton from the remote dual view console to wake a PC at the local site via RS-232, no need to go to the local site to wake up the PC. It eliminates the need for traveling back and forth between the local computer and remote console, effi cient and flexible.
Use the improved built-in front panel tuners to easily adjust the picture quality. In addition, you can automatically synchronize the time delay of RGB signals in order to compensate for distance, easy and fast than ever.
KVM Switch Features
Dual View Support - connect two screens to transmit two video output signals to a remote site up to 300 m away using inexpensive Cat 5e/6 cables
Dual Console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles
Deskew Function - automatically synchronizes the time delay of RGB signals to compensate for distance
PC Wakeup support - from the remote console, simply use a pushbutton to wake a computer at the local site via RS-232
Superior video quality - 1920x1200@60Hz(150 m), 1280x1024@60Hz(300 m)
Gain/Compensation Control - adjusts signal strength in order to compensate for distance
On Screen Display - conveniently adjust video quality with the intuitive OSD menu system
RS-232 Channel - allow you to connect to a serial terminal, or serial devices such as touchscreens and barcode scanners
Supports Wide Screen formats
Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
Sun/Mac keyboard support and emulation
Supports Wide Screen formats
Package Contents
1x CE775L USB KVM Extender (Local Unit)
1x CE775R USB KVM Extender (Remote Unit)
1x Custom KVM Cable (VGA, USB, Audio; 1.8m/6ft)
1x VGA Cable (1.8m)
2x Power Adapters
1x Mounting Kit
1x User Instructions
