Aten CS1316 16-Port PS/2-USB VGA KVM Switch

Overview

The CS1316 KVM switch allows access and control up to 256 computers from a single console (keyboard, mouse, and monitor). As many as 16 additional switches can be cascaded bringing the total number of connected computers to 256 computers that can be controlled from a single keyboard-monitor-mouse console. The switch supports both USB and PS/2 connections for the console and computers.

Package Contents

• 1x CS1316 KVM Switch with Rack Mount Kit
• 1x Console cable
• 1x Firmware Upgrade cable
• 1x Foot Pad set (4 pads)
• 1x Power Adapter
• 1x User Instructions

Features

• One USB-PS/2 console controls 16 computers
• Cascade up to 2 levels - control up to 256 computers
• Dual Interface - supports computers with PS/2 or USB keyboards and mice
• Multiplatform support - Windows 2000/XP/Vista, Linux, Mac, and Sun
• Video DynaSync™ - Exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports
• Auto PS/2 and USB interface detection
• USB or PS/2 keyboard and mouse emulation - computers boot even when the console focus is elsewhere
• Superior video quality - up to 2048 x 1536; DDC2B
• Computer selection via front panel pushbuttons, hotkeys and multilingual on-screen display (OSD) menu
• Two level password security - only authorized users view and control computers; up to four users and an administrator with a separate profile for each
• Auto Scan feature for monitoring user-selected computers
• Hot pluggable - add or remove computers without having to power down the switch
• Buzzer on/off via hotkey and OSD
• Firmware upgradeable
• No software installation required
• Designed for desktop or rack mount (19" system rack, 1U)
