The APC Smart-UPS SRTL1000RMXLI-NC is a 1000VA / 900W double-conversion on-line UPS in a 3U rackmount form factor, engineered to deliver continuous pure-sine power and scalable runtime for servers, storage, voice/data networks, medical labs, and light industrial equipment. Lithium-ion battery technology reduces the frequency of battery replacements while hot-swap capability maintains uptime during service. A preinstalled Network Management Card enables remote monitoring and integration with centralized management platforms.
Double-conversion online topology delivers continuous pure sine wave output. Output capacity is rated at 1000VA / 900W. Input uses IEC 320 C14; output includes eight IEC 320 C13 outlets. The UPS supports extended runtime with optional external battery packs and features lithium-ion chemistry for higher cycle life and reduced maintenance events.
Integrated lithium-ion battery minimizes the need for frequent battery replacements over the UPS service life. Batteries are hot-swappable for uninterrupted operation during replacement. The unit supports scalable runtime configurations with external battery options where extended runtime is required.
3U rackmount chassis includes rack ears/rails and is convertible to tower form. Designed to fit standard data center racks as well as smaller server closets. Physical design optimizes airflow and service access for on-site technicians.
Preinstalled Network Management Card provides SNMP/Web monitoring and remote control capabilities, and integrates with management platforms such as EcoStruxure IT or third-party centralized systems. Includes PowerChute Network Shutdown for graceful OS and virtualization shutdown workflows.
Front-panel LCD graphics display offers operational text and mimic diagrams for quick visual status and alarm context. On-screen menus expose configuration options and real-time system parameters for field technicians and administrators.
Supports an ECO operating mode to increase efficiency by bypassing unused internal components when incoming power quality is within acceptable ranges. Double-conversion mode maintains the highest level of protection at the cost of slightly lower efficiency.
Provides frequency and voltage regulation to correct brownouts, over-voltages, and frequency variations without relying on the battery. Built-in surge protection and EMI/RFI filtering reduce noise and transient impact on sensitive electronics (energy rating: 340 Joules).
Automatic self-test routines periodically validate battery health and detect faults early. Battery failure notifications and network alerts enable prompt preventive action. The UPS includes diagnostic codes and logs for efficient root-cause analysis.
Ideal for small-to-medium IT racks, edge compute closets, branch office servers, storage arrays, voice/data networking equipment, medical lab instrumentation, and other critical systems requiring clean, continuous power and remote management capabilities.
Input: IEC 320 C14 inlet. Output: 8 x IEC 320 C13 outlets. Network Management Card (preinstalled) provides RJ-45 network connectivity for management. Additional communication options available via the NMC interface.
Ships with PowerChute Network Shutdown to coordinate graceful shutdowns of physical and virtual environments. Integrates with EcoStruxure IT and other monitoring platforms for alarm aggregation, trending, and remote diagnostics. A Secure Network Management Card subscription is included for secure remote access and management.
Smart-UPS On-Line provides high-density, double-conversion, online power protection for servers, voice/data networks, medical labs, and light industrial applications. The Smart-UPS On-Line has a rack/tower convertible chassis. The batteries allow for greater performance at higher temperatures and greater overall lifecycle of the UPS.
