APC EPDU2116MBO Easy Metered 0U 1 Phase 3.7kW 24 outlet IEC60309 inlet Rack PDU

Easy Metered-by-outlet rack PDU EPDU2116MBO provides detailed energy analysis for individual outlets, enabling better capacity planning and resource allocation. The APC Network Management Card NMC3 provides enhanced cybersecurity with secured interfaces.

The rack PDU integrates with EcoStruxure IT through a Network Management Card (NMC3) and can be accessed and configured via Web, SNMP, and Command Line Interface. EPDU2116MBO is designed for single phase applications of upto 3.7kw and industry standards of 1% metering accuracy.

This comes with IEC 60309 16A 2P+E type inlet, Twenty IEC C13 and four IEC C19 type outlet sockets. It features an ultra-lightweight aluminum housing, offering up to 50% weight reduction, along with environmental monitoring and an all-new improved display module.

Vertical mounting capabilities allow users to mount the units in a rack or enclosure in zero U space without expending valuable rack space This is designed to operate within a temperature range of -5°C to +50°C and is backed by a standard 2-year warranty.

The rack PDU supports daisy-chain of up to 4 PDUs on a single IP address, thereby reducing networking cost. Environmental monitoring ports for external temperature/humidity monitoring is available (sensor sold separately).

Specifications

Main

• Colour: Black
• Product or component type: PDU
• PDU type: Metered outlet
• Cord length: 3 m
• Number of cables: 1
• Provided equipment: Installation guide

Complementary

• Input Voltage: 208 V
• Dimensions (H x W x D): 1800 mm x 55 mm x 56 mm
• Output Voltage: 230 V
• Net weight: 6.37 kg
• Mounting location: Side
• Mounting preference: No preference
• Input Plug Type: IEC 60309 16 A 2P + E
• Mounting mode: Not rack-mountable
• Rack units: 0U
• USB compatible: No
• Mounting position: Vertical
• Communication port protocol: SNMP
• [In] rated current: 16 A
• Permissible voltage: 200-240 V
• Max line current: 16 A
• Input current limits: 16 A
• Load capacity: 3680 VA
• Network frequency: 50/60 Hz
• Plug standard: IEC 60309
• Outlet type and quantity: 20 IEC 60320 C13
• Communication network type: 10/100BASE-T

Environment

• Product certifications: CE
• Ambient air temperature for operation: -5-50 °C
• Relative humidity: 5-95 %
• Operating altitude: 0-3000 m
• Ambient air temperature for storage: -25-65 °C
• Storage Relative Humidity: 5-95 %
• Storage altitude: 0-15000 m

Packing Units

• Unit Type of Package 1: PCE
• Number of Units in Package 1: 1
• Package 1 Dimensions (H x W x L): 203 cm x 19.5 cm x 13 cm
• Package 1 Weight: 7.54 kg

Contractual warranty

• Warranty: 2 Years repair and replace
