Allied Telesis AT-DMC100/ST-30 100Mb LAN ST multi-mode Fibre media converter

Explore the Allied Telesis AT-DMC100/ST-30 100Mb LAN ST multi-mode Fibre media converter. Compact and energy-efficient, it's a standout in the DMC series for its small size and USB-powered versatility.

Specifications

Network

• Fiber optic connector: ST
• Data transfer rate: 100 Mbit/s
• Packet forwarding rate (100 Mbps): 148800 pps
• Packet forwarding rate (10 Mbps): 14880 pps
• Packet forwarding rate (1 Gbps): 1488000 pps
• VLAN support: Yes
• Converter input interface: 100Base-TX
• Networking standards: IEEE 802.1Q
• Ethernet interface type: Fast Ethernet
• Duplex system: Full, Half
• Converter output interface: 100Base-FX
• Auto MDI/MDI-X: Yes
• Maximum data transfer rate: 100 Mbit/s

Technical Details

• Wavelength: 1310 nm
• Maximum transfer distance: 2000 m
• Fiber mode structure: Multi-mode
• Fiber cable diameters supported (core/cladding): 50/125, 62.5/125 µm
• Tx power (min): -22.5 dBmW
• Tx power (max): -14 dBmW
• Rx power (min): -32 dBmW
• Internal: Yes
• Data transfer rate: 100 Mbit/s

Ports & Interfaces

• Connectivity technology: Wired
• Fiber optic connector: ST

Indication

• LED indicators: Yes

Design

• LED indicators: Yes
• Product colour: Grey
• Internal: Yes

Power

• Power consumption (typical): 1.5 W

Dimensions

• Dimensions: Width 31.8 mm, Depth 91.4 mm, Height 21.6 mm

Weight

• Weight: 113 g

Operational Conditions

• Operating temperature (T-T): 0 - 40 °C
• Storage temperature (T-T): -15 - 65 °C
• Operating relative humidity (H-H): 5 - 95%
• Storage relative humidity (H-H): 5 - 95%
• Operating altitude:
