AirGuard Retro Fit Brushed Grommet Kit

The DCGTAG5 AIR-GUARD Kit is designed to fit into both new and existing non standard cut outs using brush seal technology, in both existing and new raised floors. The DCGTAG5 features the "better seal" overlapping brush system to form a custom fit flush grommet solution. Materials can be cut on site to seal an opening up to a maximum size of 610mm x 250mm.

• Brush sections and side rails made from flame retardant materials
• Brushes designed to overlap to form a better seal
• Brush profile fitted with adhesive tape to assist easy installation
• Side rails can be cut to form a fully protective edge
• 2 stock kit sizes - DCGTAG5-300 (310mm x 250mm) DCGTAG5-600 (610mm x 250mm)
• Custom sizes available
• Engineered side rail clips integrate with the brush sections to provide full cut-out edge protection
• As with all Air-Guard products brushes are designed to overlap offering a better air seal
• Manufactured from high strength flame retardant ABS and V0 rated quality nylon brush

Sealing around under-floor air cooled cable openings offers the following benefits:

• Reduced air-loss and increased static press for under-floor air installations
• Improved cooling efficiencies and extended cooling equipment life
• Reduced cooling plant running costs
• Facilitates Cold/Hot Aisle best practice
• Seals cable openings to prevent under-floor contamination

DCGTAG5 Dimensions:
There are 2 kit sizes to select from:
DCGTAG5-300 – Maximum Dimension 312mm x 250mm
DCGTAG5-600 - Maximum Dimension 622mm x 250mm

Air-Guard® - the cooler choice
