25G SFP28 to SFP28 Direct Attach Cable - Passive

25G SFP28 Direct Attach Passive Copper cable assemblies (DAC) are a high-performance and cost-effective 1/0 solution for 25G Ethernet applications. The SFP28 copper cables allow hardware manufactures to achieve high port density, configurability and utilization at a very low cost and reduced power budget. The high speed cable assemblies meet and exceed 25G Ethernet industry standard requirements for performance and reliability.

Features

• Support multi-gigabit data rates up to 25.8Gbps
• Improved Pluggable Form-factor (IPF) compliant for enhanced EMI/EMC performance
• MSA Compliant to SFF-8402 and SFF-8432
• Hot-pluggable SFP 20PIN footprint
• Low Power Consumption < O.SW
• Power Supply :+3.3V
• Compliant to SFP+ MSA
• Temperature Range: 0 ~ 70 °C
• ROHS
• Length up to 5m

Applications

• Storage Area Networks(SAN), Network Attached Storage and Storage Servers
• Switched fabric 1/0 such as ultra high bandwidth switches and routers
• High density connections among network equipment
• Data center cabling infrastructure
