Ubiquiti UniFi UAP AC HD Access Point - UAP-AC-HD

Upgrade your wireless network with the Ubiquiti UniFi UAP-AC-HD Access Point (UAP-AC-HD), a high-performance solution for medium to high-density environments. This access point delivers exceptional performance, versatility, and seamless integration into the Ubiquiti UniFi ecosystem.

UniFi® is the revolutionary Wi-Fi system that combines enterprise performance, unlimited scalability, and a central management controller. The UniFi AC HD AP has a refined industrial design and can be easily installed using the included mounting hardware. Easily accessible through any standard web browser and the UniFi mobile app (iOS or Android), the UniFi Controller software is a powerful software engine ideal for high-density client deployments requiring low latency and high uptime performance. Use the UniFi Controller software to quickly configure and administer an enterprise Wi-Fi network - no special training required. RF map and performance features, real-time status, automatic UAP device detection, and advanced security options are all seamlessly integrated

Features:

• Simultaneous Dual-Band 4x4 Multi-User MIMO
• Four-Stream 802.11ac Wave 2 Technology
• 802.3at PoE+ Compatibility

The Highest Performance AP in the Industry Now Happens to Be the Best Value

Multi-User MIMO Technology	4x4 Dual-Radio 2.53 Gbps Performance	500+ Client Connections

High-Density Applications Powered by MU-MIMO Technology

802.11ac Wave 2 MU-MIMO (Multi-User, Multiple Input, Multiple Output) technology allows a Wave 2 AP to communicate with multiple clients at the same time - significantly increasing multi-user throughput and overall user experience.

Radio Hardware Acceleration	CPU Hardware Acceleration	Optimised for MU-MIMO	Beamforming

Advanced Features in UniFi Controller

UniFi is the premiere Software Defined Networking (SDN) solution with seamless integration of high-performance switching, gateways, and more.

Access Point Comparison Chart

	UAP-AC-IW	UAP-AC-IW-PRO	UAP-AC-LITE	UAP-AC-LR	UAP-AC-PRO	UAP-AC-HD
Environment	Indoor	Indoor	Indoor	Indoor	Indoor/ Outdoor	Indoor/Outdoor (covered)
Simultaneous Dual-Band
2.4 GHz Speed	300 Mbps	450 Mbps	450 Mbps	450 Mbps	450 Mbps	800 Mbps
2.4 GHz MIMO	2x2	3x3	3x3	3x3	3x3	4x4
5 GHz Speed	867 Mbps	1300 Mbps	867 Mbps	1300 Mbps	1300 Mbps	1733 Mbps
5 GHz MIMO	2x2	3x3	2x2	3x3	3x3	4x4
Range			183 mt	122 mt	183 mt	122 mt
Secondary Ethernet Port	(2 Additional Ports)	(2 Additional Ports)
PoE Mode	802.3at PoE+	802.3at PoE+	802.3af/A PoE 24V Passive PoE	802.3af/A PoE 24V Passive PoE	802.3af PoE 802.3at PoE+	802.3at PoE+
Ceiling Mount
Wall Mount
Wireless Uplink
DFS Certification
Dimensions(mm)	140 x 87 x 26	140 x 87 x 26	160 x 31.5	176 x 43	197 x 35	220 x 48

Ubiquiti Extended Warranty

Ubiquiti currently offers 1 year standard manufacturer warranty on equipment purchased through official UK distributors.

In the unlikely event that you have any issues with your Ubiquiti product within the 1 year of manufacturer warranty, please contact your account manager in the first instance. Our technical team will do everything they can to find a resolution to your problem. If a fix cannot be provided, then an RMA will need to be registered via the Ubiquiti Reseller Portal.

On all purchases made through Comms Express, we offer our customers options to upgrade the standard manufacturer warranty to a 3 or 5 year advanced hardware replacement.

Available warranty options:
