Ubiquiti U-POE+ PoE Injector 30 W 48 V

Ubiquiti UniFi PoE+ Adapter (U-POE+)

Power your UniFi PoE+ devices efficiently with the Ubiquiti UniFi PoE+ Adapter (U-POE-AT). This adapter is designed to support wireless mesh applications and reduce dependency on PoE switches.

Key Features:

• High Power Delivery: Provides up to 30W of PoE+ power.
• Wide Compatibility: Works seamlessly with U6 LR, U6 Pro, and other PoE+ devices.
• Enhanced Protection: Equipped with surge, peak pulse, and overcurrent protection.
• Reliable Connection: Includes an AC cable with earth ground for stable power supply.
• Status Monitoring: Features an LED indicator for easy status monitoring.

Technical Specifications:

• Model: U-POE-AT
• Dimensions: 93 x 62 x 35 mm (3.66 x 2.44 x 1.38")
• Weight: 156 g (5.5 oz)
• Output Voltage: 48VDC @ 0.65A
• LAN Activity Indicator: No
• Gigabit LAN Port: Yes
• Remote Reset Capability: Yes
• Reset Button: No
• Rated Voltage: 100-240VAC @ 50/60Hz
• Input Current: 0.75A@90VAC
• Inrush Current: <100A Peak @230VAC, 26?
• Efficiency: 87%
• Output Ripple: 1% Max.
• Switching Frequency: 70 kHz Max.
• Line Regulation: ? 3%
• Load Regulation: ? 5%
• 2-Pair Powering: Pins 4, 5 (+) and Pins 7, 8 (-)
• Operating Temperature: 0 to 40° C (32 to 104° F)
• Storage Temperature: -30 to 70°C (-22 to 158° F)
• Operating Humidity: 35 to 90% Noncondensing
• AC Connector: IEC-320 C6
